Case IH 2388 Combines
Case IH 2388
5+
sold in last yearGeneral overview
Case IH 2388 is a combine harvester built for grain harvesting in field operations. It uses a diesel engine with an 8.3 L displacement and is listed with an emission standard level of Tier 2 or 3, transition. The model is identified with a rated power of 285 kW (388 hp) and an engine power of 320 kW (435 hp), placing it in a higher-output class for combine work.
Its grain-handling system includes a 7,400 L (1,955 US gal) grain tank and a peak unloading rate of 67 L/s (1.9 bu/s), which supports continuous harvest flow. A Rotary AFX separator, 135° threshing area wrap, and 5.13 m² (55.2 sq ft) sieve area describe the separation and cleaning layout, while wheel propulsion supports field movement. Together these features support harvesting, separation, and grain handling in one pass.
Year
1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,760 mm
~148 in
4,110 mm
~161.8 in
8,270 mm
~325.6 in
12,850 kg
~28,329.4 lb
Engine Power
320 hp
Emission standard level
Tier 2 or 3, transition
Grain tank size
7,400 L
Peak unloading rate
67 L/sec
Additional specifications
Engine type
Diesel
Displacement
8,300 cu(cm)
Fuel tank
680 L
Type of propulsion
Wheel
Separator type
Rotary AFX
Threshing Area Wrap
135 deg
Sieve area
5.127 sq(m)
Unloading auger length
4.37 m
Unloading rate
67 L/sec
Rated power
285 hp
Case IH 2388 Combines Listings
Looking for Case IH 2388 Combines?
See similar listingsCompare Case IH 2388 Combine to other combines
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
4.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
4.0
Reliability & Durability
4.0
Comfort & Ergonomics
5.0
Safety
5.0
Technology & Features
4.0
Stephen Schroeder
It runs across canola, spring wheat and milo for us. The automation pulls real fatigue out of a long beans day. A big tank and fast unload cut our wait on the grain cart in beans.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH 2388?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Case IH 2388?
Listed features include a Rotary AFX separator, 7,400 L grain tank, 67 L/s unloading rate, wheel propulsion, and 238.6 kW (320 hp) engine power. These specifications can help buyers assess harvesting capacity and unloading capability.
What type of engine does the 2388 use?
The 2388 uses a Diesel engine with 8,300 cc displacement.
How much horsepower does the 2388 have?
Engine Power is 238.6 kW (320 hp). Rated power is 212.5 kW (285 hp).
What fuel does the Case IH 2388 use?
The Case IH 2388 uses Diesel fuel. Its fuel tank capacity is 680 L (179.6 US gal).
What jobs is this Combines best suited for?
The supplied data identifies this machine as a combine with a Rotary AFX separator. Its suitability for particular crops, field conditions, or harvesting jobs is not confirmed by the supplied information.
What is the expected lifespan of the 2388?
The supplied data does not provide an expected service life. For a used combine, inspect maintenance records, engine condition, separator components, unloading system, fuel system, and overall operating condition.
What should a buyer check when purchasing a used Combines?
Check maintenance records, engine condition, fuel system, separator components, sieve area condition, grain tank, unloading auger, and unloading system. Verify that the wheel propulsion system operates properly and inspect the machine for wear, leaks, damage, and missing parts.
