Massey Ferguson 9540 Combines
MASSEY FERGUSON 9540
5+
sold in last yearGeneral overview
Massey Ferguson 9540 is a combine harvester manufactured in the United States and produced from 2012 to 2015. It is built for grain harvesting in field conditions, where cutting, threshing, and grain separation are performed in a single pass. The machine is powered by a diesel engine and is rated at 272 kW (370 hp), with an engine power figure of 313 kW (426 hp) and Tier 4 Interim emissions compliance.
Key operating features include wheel propulsion and a rotary separator, which define its harvesting configuration. Capacity-focused specifications include a grain tank size of 12,334 L (3,258 US gal), a peak unloading rate of 141 L/s (2,235 gpm), and an unloading auger length of 6.4 m (21 ft). The sieve area is 6.1 m² (65.7 sq ft), supporting crop cleaning during harvest.
Year
2012, 2013, 2014, 2015
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,840 mm
~151.2 in
3,730 mm
~146.9 in
9,800 mm
~385.8 in
17,550 kg
~38,691.2 lb
Engine Power
426 hp
Emission standard level
Tier 4 Interim
Grain tank size
12,334 L
Peak unloading rate
141 L/sec
Additional specifications
Engine type
Diesel
Displacement
598 cu(in)
Fuel tank
870 L
Type of propulsion
Wheel
Separator type
Rotary
Threshing Area Wrap
142 deg
Sieve area
6.1 sq(m)
Unloading auger length
6.4 m
Unloading rate
141 L/sec
Rated power
370 hp
Massey Ferguson 9540 Combines Listings
Looking for Massey Ferguson 9540 Combines?
See similar listingsCompare Massey Ferguson 9540 Combine to other combines
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Massey Ferguson 9540?
No confirmed market price is supplied. Check current listings while considering the machine’s condition, location, and configuration.
What are the key advantages of the Massey Ferguson 9540?
Listed features include a rotary separator, 12,334 L grain tank, 141 L/s unloading rate, 6.1 m² sieve area, and 317.7 kW (426 hp) engine power. It also has wheel propulsion and a 6.4 m unloading auger.
What type of engine does the 9540 use?
The 9540 uses a Diesel engine with 598 cu in displacement and a Tier 4 Interim emission standard level.
How much horsepower does the 9540 have?
The 9540 has 317.7 kW (426 hp) engine power. Its rated power is 275.9 kW (370 hp).
What fuel does the Massey Ferguson 9540 use?
The Massey Ferguson 9540 uses Diesel fuel. Its fuel tank capacity is 870 L (229.8 US gal).
What jobs is this combine best suited for?
As a combine with a rotary separator, the 9540 is suited to grain harvesting operations. The supplied specifications list a 12,334 L grain tank and 141 L/s unloading rate, which are relevant for harvesting and unloading grain.
What is the expected lifespan of the 9540?
The supplied data does not confirm an expected service life. For a used machine, assess maintenance history, operating condition, wear in harvesting and unloading components, and the condition of the engine and fuel system.
What should a buyer check when purchasing a used combine?
Check maintenance records, engine condition, fuel system, rotary separator, threshing and sieve components, grain tank, unloading auger, and unloading system. Inspect for wear, leaks, damage, and signs that all functions operate correctly.
