John Deere 772CH II Motor Graders
John Deere 772CH II
5+
sold in last yearGeneral overview
The John Deere 772CH II is a motor grader designed for grading, shaping, and maintaining surfaces in construction work. It is powered by a John Deere 6081H (8.1L PowerTechâ„¢) six-cylinder engine rated at 166 kW (226 hp) and meets Tier 2 emissions requirements. The model also has an articulated mainframe and a moldboard width of 4,267 mm (14 ft).
With an operating weight of 17,160 kg (37,830 lb), the 772CH II is built around controlled blade work in demanding grading environments. A direct-drive John Deere PowerShift Plus™ (modulated shift on-the-go) transmission, 25° articulation, and 5° front axle wheel lean angle each direction support maneuvering during operation. The blade system includes 360° circle rotation, 686 mm (27 in) side shift, and 49 mm (2 in) lift above ground, while the front scarifier provides a 2,235 mm (7 ft 4 in) width of cut.
Year
2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Width
8,611 mm
~339 in
2,512 mm
~98.9 in
Engine Power
226 hp
Operating Weight
17,160 kg
Moldboard Width
4,267 mm
Additional specifications
Emission standard level
Tier 2
Displacement
8 cu(m)
Fuel tank
401 L
Cooling system
59 L
Overall length w/header
8,611 mm
Height to top of cab
1,524 mm
Wheelbase
5,940 mm
Number of Cylinders
6
Battery Voltage
24
Overall width
2,512 mm
Maximum Travel Speed - High
41 km/h
Engine Oil
36 L
Maximum Digging Depth
432 mm
Net Power (ISO 9249)
210 hp
Manufacturer and Model
John Deere 6,081H (8.1L PowerTechâ„¢)
Net Peak Torque
1,025 Nm
Alternator Rating
55
Hydraulic System
75 L
Main Pump Type
Closed Center Variable displacement
Powertrain Type
Direct-drive John Deere PowerShift Plusâ„¢ (modulated shift on-the-go)
Gears Forward
8
Gears Reverse
8
Front Axle Wheel Lean Angle (each direction)
5 deg
Steering (Turning Radius)
6 m
Steering (Articulation)
25 deg
Maximum Pump Flow
207 L/min
Maximum System Pressure
17,580 kPa
Blade Function
Power Shift (8 forward, 8 reverse); circle rotates 360 degrees
Blade Range - Lift Above Ground
49 mm
Blade Range - Blade Side Shift (right or left)
686 mm
Pitch at Ground Line - Forward
49 deg
Pitch at Ground Line - Back
5 deg
Shoulder Reach Outside Wheels (frame straight, right or left)
610 mm
Blade Pull At Maximum Operating Weight
19,890 kg
Tandem Axle Spacing
1,540 mm
Blade Base
686 mm
Mainframe Type
Articulated
Circle - Consruction
360-degree rotation mm
Circle Rotation
360 deg
Circle Side Shift (right)
787 mm
Height (measured along arc, including cutting edge)
610 mm
Moldboard Thickness
25 mm
Cutting Edge - Thickness
22 mm
Cutting Edge - Width
610 mm
Scarifiers - Type
Front scarifier
Width of Cut
2,235 mm
Number of Shanks/Teeth
9
Shank - Size
57,140 mm
Front Lift Group - Type
Front scarifier
Ground Clearance (front axle)
152 mm
Operating Weight - Front
4,620 kg
Operating Weight - Rear
10,390 kg
Circle Diameter
1,524 mm
Operating Weights - Total
17,160 kg
John Deere 772CH II Motor Graders Listings
Looking for John Deere 772CH II Motor Graders?
See similar listingsCompare John Deere 772CH II Motor Grader to other motor graders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 772CH II?
No confirmed market price is supplied for the John Deere 772CH II. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the John Deere 772CH II?
Listed features include 168.5 kW (226 hp) engine power, an articulated mainframe, a 4,267 mm (168 in) moldboard, and direct-drive John Deere PowerShift Plus™ transmission with 8 forward and 8 reverse gears. The circle rotates 360°.
What type of engine does the 772CH II use?
The 772CH II uses a John Deere 6081H (8.1L PowerTechâ„¢) engine. It has 6 cylinders and a Tier 2 emission standard level.
How much horsepower does the 772CH II have?
The 772CH II is listed with 168.5 kW (226 hp) engine power. Its net power under ISO 9249 is 156.6 kW (210 hp).
What fuel does the John Deere 772CH II use?
The supplied specifications do not confirm the fuel type for the John Deere 772CH II. They list a 401 L (105.9 US gal) fuel tank.
What jobs is this Motor Graders best suited for?
The supplied data does not specify intended applications. Its listed equipment includes a 4,267 mm (168 in) moldboard, 360° circle rotation, articulated mainframe, and front scarifier with 9 shanks/teeth.
What is the expected lifespan of the 772CH II?
No expected service-life estimate is supplied for the 772CH II. For a used machine, inspect service records, engine condition, transmission operation, hydraulic performance, moldboard and circle wear, scarifier components, and structural condition.
What should a buyer check when purchasing a used Motor Graders?
Check service records, engine condition, transmission shifting, hydraulic operation, and signs of leaks. Inspect the moldboard, cutting edge, circle, scarifier, axle components, tires, articulation joint, cab controls, and overall frame condition. Confirm that all functions operate properly during an inspection.
