John Deere 672GP Motor Graders
John Deere 672GP
5+
sold in last yearGeneral overview
John Deere 672GP is a motor grader designed for grading and shaping surfaces in construction work. Manufactured in the United States, it uses a John Deere PowerTechâ„¢ PSS 9.0L engine rated at 187 kW (255 hp). The operating weight is 17,116 kg (37,730 lb), giving the model a heavy-duty size class for sustained blade work.
The 672GP uses Automatic dual-path hydrostatic drive / multiple wet discs and offers 8 gears forward and 8 gears reverse. Key dimensions include a 3,658 mm (12 ft) moldboard width, a 2,570 mm (8 ft 5 in) blade base, and a 6,160 mm (20 ft 3 in) wheelbase. Maximum travel speed is 40 km/h (24.9 mph).
Year
2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
8,880 mm
~349.6 in
3,175 mm
~125 in
2,650 mm
~104.3 in
Engine Power
255 hp
Operating Weight
17,116 kg
Moldboard Width
3,658 mm
Additional specifications
Displacement
9 cu(m)
Fuel tank
416 L
Overall length w/header
8,890 mm
Height to top of cab
3,180 mm
Wheelbase
6,160 mm
Number of Cylinders
6
Battery Voltage
24
Overall width
2,640 mm
Maximum Travel Speed - High
40 km/h
Net Power (ISO 9249)
255 hp
Manufacturer and Model
John Deere PowerTechâ„¢ PSS 9.0L
Net Peak Torque
1,273 Nm
Hydraulic System
60 L
Powertrain Type
Automatic dual-path hydrostatic drive / multiple wet discs
Gears Forward
8
Gears Reverse
8
Maximum Pump Flow
212 L/min
Maximum System Pressure
18,960 kPa
Blade Pull At Maximum Operating Weight
22,453 kg
Blade Base
2,570 mm
Operating Weights - Total
17,116 kg
John Deere 672GP Motor Graders Listings
Looking for John Deere 672GP Motor Graders?
See similar listingsCompare John Deere 672GP Motor Grader to other motor graders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 672GP?
No confirmed market price is supplied. Check current listings and compare the machine’s condition, location, and configuration.
What are the key advantages of the John Deere 672GP?
Listed strengths include 190.2 kW (255 hp) net power, a 3,658 mm (144 in) moldboard, 8 forward and 8 reverse gears, and a maximum travel speed of 40 km/h (24.9 mph). Its operating weight is 17,116 kg (37,734 lb).
What type of engine does the 672GP use?
The 672GP uses a John Deere PowerTechâ„¢ PSS 9.0L engine with 6 cylinders.
How much horsepower does the 672GP have?
The 672GP has 190.2 kW (255 hp) of engine power. Its net power under ISO 9249 is also listed as 190.2 kW (255 hp).
What fuel does the John Deere 672GP use?
The supplied specifications do not confirm the fuel type for the John Deere 672GP. They list a fuel tank capacity of 416 L (109.9 US gal).
What jobs is this Motor Graders best suited for?
The supplied information identifies the 672GP as a motor grader. It does not specify particular job applications or site conditions for which this model is best suited.
What is the expected lifespan of the 672GP?
The supplied data does not provide an expected service life for the 672GP. For a used machine, assess maintenance records, operating condition, wear on the moldboard and drivetrain, hydraulic performance, and cab condition.
What should a buyer check when purchasing a used Motor Graders?
Check maintenance records, overall operating condition, hydraulic-system performance, drivetrain operation, moldboard wear, tire condition, cab condition, and signs of leaks or damage. Confirm that the machine’s configuration and specifications match the intended application.
