Case IH Steiger 500 Quadtrac Tracked Tractors (4 Tracks)
Case IH Steiger 500 Quadtrac
Average price
$162,500
5+
sold in last year
General overview
Case IH Steiger 500 Quadtrac is a tracked tractor built for high-horsepower fieldwork in large-scale farm operations. It uses a 12 L diesel engine rated at 368 kW (500 hp) and meets Tier 4 Interim emissions requirements, placing it in a high power class for demanding traction tasks.
The model is equipped with a Powershift transmission, an independent rear PTO, and a PTO speed of 1,000 rpm. PTO output is listed at 320 kW (435 hp) rated and 368 kW (501 hp) maximum. Hydraulic equipment includes a closed center pressure flow compensated system with a pump rated output of 159 L/min (42 gpm), 132 L/min (34.9 gpm) available at a single rear SCV, and four rear selective control valves. A Category 4N rear 3-point hitch supports a maximum lift capacity behind the lift points of 8,900 kg (19,620 lb), and the tractor is guidance ready.
Year
2013, 2019
Country of manufacturing
United States
General specifications
Dimensions
Width
3,048 mm
~120 in
Tire or Track Type
4_tracks
Engine Power
500 hp
Track Width
2.29 m
Additional specifications
Emission standard level
Tier 4 Interim
Engine type
diesel
Displacement
12 cu(m)
Maximum PTO power
501 hp
Rated PTO power
435 hp
Transmission type
Powershift
Maximum lift capacity behind lift points
8,900 kg
Fuel tank
1,173 L
Hydraulic system type
closed center pressure flow compensated
Pump rated output
159 L/min
Available flow at a single rear SCV
132 L/min
Number of rear selective control valves
4
Hitch type
4N
Rear PTO
independent
Rear 3-Point Hitch
Category 4N
Guidance Ready
guidance_ready
PTO speed
1,000
Case IH Steiger 500 Quadtrac Tracked Tractors (4 Tracks) Listings
$162,500
Power Shift
4_tracks
500 hp
4751 hours
Three Rivers, United States
Compare Case IH Steiger 500 Quadtrac Tracked Tractors (4 Tracks) to other tracked tractors (4 tracks)
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Case IH Steiger 500 Quadtrac Tracked Tractors (4 Tracks)
4_tracks
3048 mm
Add model
Add model
4.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
5.0
Reliability & Durability
3.0
Comfort & Ergonomics
4.0
Safety
5.0
Technology & Features
4.0
Richard Rogers
It pulls a 36-foot high-speed disk for us without complaint. There's enough hydraulic flow to run a 40-foot chisel plow wide open. My only gripe is that cab noise creeps up a little at road speed.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH Steiger 500 Quadtrac?
No confirmed market price is supplied. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Case IH Steiger 500 Quadtrac?
Listed features include a 4_tracks configuration, 372.9 kW (500 hp) engine power, Powershift transmission, independent rear PTO, Category 4N rear 3-point hitch, and a closed center pressure flow compensated hydraulic system with 4 rear selective control valves.
What type of engine does the Steiger 500 Quadtrac use?
The Steiger 500 Quadtrac uses a diesel engine and is listed with a Tier 4 Interim emission standard level.
How much horsepower does the Steiger 500 Quadtrac have?
Engine power is listed as 372.9 kW (500 hp). Rated PTO power is 324.4 kW (435 hp), while maximum PTO power is 373.6 kW (501 hp).
What fuel does the Case IH Steiger 500 Quadtrac use?
It uses diesel fuel. The listed fuel tank capacity is 1,173 L (309.9 US gal).
What jobs is this Tractors best suited for?
The supplied data does not specify intended jobs. Its listed equipment includes 4_tracks, 372.9 kW (500 hp), a Category 4N rear 3-point hitch, an independent rear PTO, and hydraulic flow from a closed center pressure flow compensated system.
What is the expected lifespan of the Steiger 500 Quadtrac?
The supplied data does not confirm an expected service life. Assess maintenance records, operating history, engine condition, transmission operation, hydraulic performance, and track condition when evaluating an individual machine.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, engine operation, Powershift transmission shifting, hydraulic performance, rear PTO function, hitch operation, selective control valves, fuel-system condition, and wear or damage to the 4_tracks. Confirm that guidance-ready equipment and installed configuration match the listing.
