Case IH Patriot 3340 Self-Propelled Sprayers
Case IH Patriot 3340
Average price
$107,500
5+
sold in last year
General overview
Case IH Patriot 3340 is a farm sprayer designed for field application of crop protection and liquid inputs in crop production. Produced in the United States from 2014 to 2022, it is rated at 209 kW (285 hp) and meets Tier 3 emission standard level. The model is built around a 6.7 L (411 cu in), 6-cylinder power unit.
Operational features center on hydrostatic drive with infinitely variable shifting, AIM Command FLEX sprayer control, and compatibility with Case IH AFS Pro 700 or Case IH Viper 4+. It offers a 3,785 L (1,000 US gal) solution system capacity, 18.3 m (60 ft) boom length options, and a trailing-link w/coil spring & shock std; Active susp. opt. Transport speed is 48 km/h (29.8 mph).
Year
2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,500 mm
~137.8 in
3,700 mm
~145.7 in
8,800 mm
~346.5 in
11,367 kg
~25,060 lb
Solution System Capacity
3,785 L
Length Options
18.3 m
Additional specifications
Emission standard level
Tier 3
Displacement
411 cu(in)
Fuel tank
454 L
Number of Cylinders
6
Transport speed
48 km/h
Rated power
285 hp
Rinse tank capacity
424 L
Breakaway length
1.7 m
Boom sections
5 or 6 w/90; 6 w/100; 7 w/120; or 36 w/AIM Command FLEX
Type Drive
Hydrostatic
Shifting
Infinitely variable
Hydraulic reservoir capacity
110 L
Operator seat description
Optima Air w/swivel
Sprayer control
AIM Command FLEX, using Case IH AFS Pro 700 or Case IH Viper 4+
Suspension
Trailing-link w/coil spring & shock std; Active susp. opt.
Ground clearance with standard tires
132 m
Factory-installed
380/90R46
Tire Options
320/90R46
Turning radius
7.1 m
Solution pump
Centrifugal-hydraulic motor driven
Case IH Patriot 3340 Self-Propelled Sprayers Listings
$107,500
424 L
132 m
380/90R46
2850 hours
Iowa, United States
Compare Case IH Patriot 3340 Self-Propelled Sprayer to other self-propelled sprayers
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Case IH Patriot 3340 Self-Propelled Sprayer
3785 L
11367 kg
8800 mm × 3500 mm × 3700 mm
Add model
Add model
5.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
5.0
Reliability & Durability
4.0
Comfort & Ergonomics
5.0
Safety
5.0
Technology & Features
4.0
Lonnie Thompson
We custom-spray about 2,600 acres beyond our own ground. Individual nozzle control noticeably trimmed our skips over 7,500 acres. That said, a hydraulic line issue cost us a day once.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH Patriot 3340?
No confirmed market price is supplied for the Case IH Patriot 3340. Check current listings and compare machine condition, location, configuration, and included equipment.
What are the key advantages of the Case IH Patriot 3340?
Listed features include a 3,785 L (999.9 US gal) solution system, hydrostatic infinitely variable drive, AIM Command FLEX spray control, and a centrifugal hydraulic-motor-driven solution pump. It also has trailing-link suspension with coil springs and shocks as standard, with Active suspension optional.
What type of engine does the Patriot 3340 use?
The supplied specifications do not confirm the engine make or model. They list a Tier 3 engine with 6 cylinders and 411 cu in displacement.
How much horsepower does the Patriot 3340 have?
The Patriot 3340 has rated power of 212.5 kW (285 hp).
What fuel does the Case IH Patriot 3340 use?
The supplied specifications do not confirm the fuel type. They list a fuel tank capacity of 454 L (119.9 US gal).
What jobs is this Sprayers best suited for?
As a farm sprayer, the Case IH Patriot 3340 is suited to agricultural spray applications. Its listed solution capacity, boom-section options, AIM Command FLEX control, and transport speed support field spraying work, but the supplied data does not specify particular crops or application types.
What is the expected lifespan of the Patriot 3340?
The supplied data does not provide an expected service life for the Patriot 3340. Assess maintenance records, solution-system condition, pump operation, suspension, tires, and spray-control function when evaluating an individual machine.
What should a buyer check when purchasing a used Sprayers?
Check maintenance records and inspect the solution tank, rinse tank, pump, hoses, booms, boom sections, tires, suspension, hydrostatic drive, and spray controls. Test for leaks, proper folding and section operation, steering response, and accurate control-system function.
