Caterpillar 299D3 Skid Steer / CTL
Caterpillar 299D3
Average price
$70,700
5+
sold in last year
General overview
The Caterpillar 299D3 is a skid steer loader used for construction material handling, loading, and general jobsite work. It is powered by a Cat C3.8 DIT engine rated at 72 kW (98 hp), with net power of 70 kW (95 hp), and it uses a hydrostatic transmission for variable-speed operation. It meets Tier 4 Final / Stage V emissions standards.
Key operating figures include a rated operating capacity of 1,580 kg (3,480 lb), a tipping load of 4,520 kg (9,960 lb), and a dump height of 3,208 mm (10 ft 6 in). The model is specified with 400 mm (15.7 in) or 450 mm (17.7 in) steel-embed rubber track, and it can reach 13 km/h (8.1 mph) in two-speed configuration.
Year
2019, 2020, 2021, 2022, 2023, 2024, 2025
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,931 mm
~154.8 in
4,032 mm
~158.7 in
1,931 mm
~76 in
Engine Power
98 hp
Operating Weight
5,114 kg
Rated Operating Capacity
1,580 kg
Dump Height
3,208 mm
Max. speed
13 km/h
Additional specifications
Emission standard level
Tier 4 Final / Stage V
Displacement
3 cu(m)
Speeds
Two speed (one-speed available); Two-speed max 13.5 km/h, One-speed 8.4 km/h
Fuel tank
120 L
Number of batteries
1
Wheelbase
1,767 mm
Axles
Independent torsion axles (4)
Battery Voltage
12
Net Power (ISO 9249)
95 hp
Manufacturer and Model
Cat C3.8 DIT
Alternator Rating
100
Pump flow loader
86 L/min
2 Speed High
13 km/h
Brakes
Spring applied, hydraulically released, wet multi-disc parking brakes
System Pressure at Couplers
23,000 kPa
Hydraulic Horsepower Flow
44 hp
Length Without Bucket
3,189 mm
Width Without Bucket
1,931 mm
Height to Top of ROPS
2,125 mm
Height to Hinge Pin
3,208 mm
Dump Reach With Construction Bucket
852 mm
Ground Clearance
245 mm
Angle of Departure
33 deg
Dump Angle (full lift height)
54 deg
Bucket Rollback (ground level)
25 deg
Tipping Load
4,520 kg
SAE Rated Operating Capacity With Counterweight
2,380 kg
Boom Breakout Force With Construction Bucket
27 kg
Bucket Breakout Force With Construction Bucket
32 kg
Powertrain Type
Hydrostatic Transmission
Operating Weight - Rear
5,200 kg
Standard features
400 mm (15.7 in) or 450 mm (17.7 in) steel-embed rubber track
Seed spacing
8 mm
Cylinders
4
Caterpillar 299D3 Skid Steer / CTL Listings
$70,700
13 km/h
98 hp
1580 kg
1273 hours
Aberdeen, United States
Compare Caterpillar 299D3 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
2.0
Rating
Based on ratings and reviews from verified buyers.
Overall rating
1 reviews
5
4
3
2
1
Performance & Productivity
2.0
Reliability & Durability
1.0
Comfort & Ergonomics
3.0
Safety
3.0
Technology & Features
2.0
Brent Thomas
It logs about 5,000 hours a year for us. Grease points are easy to get at for service. It's smooth and quiet with good visibility out the front.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Caterpillar 299D3?
No confirmed market price is supplied for the Caterpillar 299D3. Check current listings and compare machine condition, location, hours, attachments, and configuration.
What are the key advantages of the Caterpillar 299D3?
The supplied specifications list 73.1 kW (98 hp) engine power, a rated operating capacity of 1,580 kg (3,483 lb), hydrostatic transmission, and a 120 L (31.7 US gal) fuel tank. Available track options are 400 mm (15.7 in) or 450 mm (17.7 in) steel-embed rubber track.
What type of engine does the 299D3 use?
The 299D3 uses a Cat C3.8 DIT engine. It has 4 cylinders and is listed with Tier 4 Final / Stage V emission standard level.
How much horsepower does the 299D3 have?
The Caterpillar 299D3 is listed with Engine Power of 73.1 kW (98 hp). Its Net Power (ISO 9249) is 70.8 kW (95 hp).
What fuel does the Caterpillar 299D3 use?
The supplied data does not confirm the fuel type for the Caterpillar 299D3. It lists a 120 L (31.7 US gal) fuel tank but does not identify the fuel.
What jobs is this Skid Steer Loaders best suited for?
The supplied data does not confirm specific intended jobs for the Caterpillar 299D3. Buyers can assess suitability against the listed rated operating capacity, dump height, hydraulic flow, track options, and available attachments.
What is the expected lifespan of the 299D3?
No expected service-life figure is supplied for the 299D3. For a used machine, inspect maintenance records, engine operation, hydraulic performance, undercarriage condition, tracks, controls, and signs of leaks or structural damage.
What should a buyer check when purchasing a used Skid Steer Loaders?
Check service records, engine starting and operation, hydraulic hoses and couplers, pump performance, controls, brakes, tracks or tires, undercarriage, attachment compatibility, leaks, frame damage, and safety equipment. Confirm that the machine’s operating capacity and dimensions fit the planned work.
