Caterpillar 140M2 AWD Motor Graders
Caterpillar 140M2 AWD
Average price
$105,000
5+
sold in last year
General overview
Year
2013
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
10,140 mm
~399.2 in
3,300 mm
~129.9 in
2,550 mm
~100.4 in
20,707 kg
~45,651.2 lb
Additional specifications
Engine Power
264 hp
Displacement
9,300 cu(cm)
Fuel tank
416 L
Length
10,140 mm
Operating Weight
20,707 kg
Engine Oil
30 L
Manufacturer and Model
Cat C9.3 ACERT
Hydraulic System
100 L
Cab Height
3,287 mm
Gears Forward
8
Gears Reverse
6
Front Axle Oscillation (total)
32 deg
Front Axle Wheel Lean Angle (each direction)
18 deg
Maximum Pump Flow
210 L/min
Maximum System Pressure
24,150 kPa
Height to Top of Exhaust
3,242 mm
Width of Cut
1,205 mm
Rear Ripper/Scarifier - Width of Cut
2,133 mm
Operating Weight - Front
6,139 kg
Operating Weight - Rear
14,568 kg
Moldboard Width
3,658 mm
Engine number of cylinders
6
Hydraulics pump type
Variable Piston
Operating weight total
20,707 kg
Powertrain transmission
Direct Drive, Powershift
Rear ripper scarifier force penetration
9,386 kg
Rear ripper scarifier force pry out
12,544 kg
Caterpillar 140M2 AWD Motor Graders Listings
$105,000
264 hp
3658 mm
20707 kg
11725 hours
Rapid City, United States
Compare Caterpillar 140M2 AWD Motor Grader to other motor graders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Caterpillar 140M2 AWD Motor Grader
20707 kg
10140 mm × 2550 mm × 3300 mm
