Case IH MAGNUM 275 Row Crop Tractors
Case IH MAGNUM 275
5+
sold in last yearGeneral overview
Case IH MAGNUM 275 is a wheel tractor built in the United States for agricultural field work. It is powered by an 8 L diesel engine rated at 202 kW (275 hp) and meets Tier 3 emissions standards. It was produced from 2007 to 2011.
An 18x4 Full Powershift transmission, MFWD front axle, and independent rear PTO define its operating setup. The tractor uses a Category III / IIIN rear 3-point hitch with a maximum lift capacity behind lift points of 6,886 kg (15,180 lb). Its closed-center, pressure-flow compensated / load-sensing hydraulic system has a pump rated output of 167 L/min (44.1 gpm), and rated PTO power is 165 kW (225 hp) with maximum PTO power of 199 kW (271 hp).
Year
2007, 2008, 2009, 2010, 2011
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Weight
3,268 mm
~128.7 in
3,264 mm
~128.5 in
14,742 kg
~32,500.6 lb
Tire or Track Type
wheels
Engine Power
275 hp
Additional specifications
Emission standard level
Tier 3
Engine type
diesel
Displacement
8 cu(m)
Maximum PTO power
271 hp
Rated PTO power
225 hp
Transmission type
18x4 Full Powershift
Maximum lift capacity behind lift points
6,886 kg
Fuel tank
681 L
Hydraulic system type
Closed-center, pressure-flow compensated / load-sensing
Pump rated output
167 L/min
Number of rear selective control valves
3
SCV control
Electro-hydraulic remote valves
Sensing type
Electronic draft and position control
Hitch type
3
Rear PTO
Independent rear PTO
Front Axle
MFWD front axle, optional suspended front axle
Rear 3-Point Hitch
Category III / IIIN
Tire width
380 mm
Additional Options
Suspended front axle, dual wheels, multiple tire packages, extra SCVs, ballast/weights
Tire type
Radial agricultural row-crop tires
PTO speed
["1,000"]
Tire Size
Front 380/85R34, rear 480/80R46; alternative front 420/90R30, rear 520/85R42
Case IH MAGNUM 275 Row Crop Tractors Listings
Looking for Case IH MAGNUM 275 Row Crop Tractors?
See similar listingsCompare Case IH MAGNUM 275 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Case IH MAGNUM 275 Row Crop Tractor
wheels
14742 kg
3268 mm × 3264 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
October 5, 2026
How to Choose the Right Excavator Bucket: Types, Sizes, and Contractor Buying Guide
This guide covers excavator bucket types, capacities, compatibility, and how to choose the right bucket for your jobsite.
September 28, 2026
Mini Excavator Buying Guide 2026: Best Models, Sizes and How to Choose
This guide breaks down everything you need to know about compact earthmoving equipment.
September 21, 2026
Types of Forklifts: Complete Guide to Classes, Uses, and Applications
This guide covers official forklift classes, physical machine variations, and load capacities.
October 9, 2026
Motor Grader Buying Guide: Sizes, Top Brands, and What Contractors Should Look For
This guide helps buyers select the right motor grader for their needs and maximize ROI across construction, mining, and snow removal.
August 25, 2026
Repair, Rebuild or Replace Heavy Equipment: 2026 Cost-Based Decision Guide
This guide provides a mathematical approach to help you decide what to do with your aging machinery in 2026.
July 31, 2026
How to Inspect Used Heavy Equipment Remotely: Practical Checklist for International Buyers
This article provides a practical, step-by-step guide for evaluating machinery without physical access.
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH MAGNUM 275?
No confirmed market price is supplied for the Case IH MAGNUM 275. Check current listings and compare condition, location, configuration, tire setup, and fitted options.
What are the key advantages of the Case IH MAGNUM 275?
Key listed features include 205.1 kW (275 hp) engine power, an 18x4 Full Powershift transmission, MFWD front axle, closed-center pressure-flow compensated / load-sensing hydraulics, 167 L/min (44.1 gpm) pump output, and electronic draft and position control.
What type of engine does the MAGNUM 275 use?
The MAGNUM 275 uses a diesel engine with a Tier 3 emission standard level.
How much horsepower does the MAGNUM 275 have?
The MAGNUM 275 has 205.1 kW (275 hp) of engine power. Rated PTO power is 167.8 kW (225 hp), and maximum PTO power is 202.1 kW (271 hp).
What fuel does the Case IH MAGNUM 275 use?
The Case IH MAGNUM 275 uses diesel fuel.
What jobs is this Tractors best suited for?
The supplied specifications do not identify particular jobs. Its listed equipment includes a rear Category III / IIIN hitch, independent rear PTO, MFWD front axle, and hydraulic remote valves; suitability depends on the implement, configuration, and operating requirements.
What is the expected lifespan of the MAGNUM 275?
The supplied data does not confirm an expected service life for the MAGNUM 275. For a used machine, assess maintenance records, operating hours, engine condition, transmission operation, hydraulics, PTO, hitch, axle, and tire condition.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, operating hours, engine starting and condition, transmission shifts, hydraulic function and leaks, PTO operation, rear hitch lift and controls, front axle condition, tire wear, brakes, steering, electrical systems, and all fitted options. Test the tractor under load where possible.
