Brandt 1380XL Grain Auger
Brandt 1380XL
Average price
$23,900
5+
sold in last year
General overview
Brandt 1380XL is a grain auger used for moving harvested grain in farm handling operations. It is designed for 540 PTO operation and lists 118 kW (160 hp) recommended PTO horsepower, indicating a tractor-powered setup. The intake diameter is 330 mm (13 in), supporting grain intake at handling points.
With a capacity of 11,000 bu/h, the Brandt 1380XL is built for grain transfer. Its construction includes 12 ga tube thickness, 6.35 mm main flighting, 76.2 mm (3 in) core diameter, 44 mm (2 in) lower bearing size, and 44 mm (2 in) gearbox shaft diameter. A scissor lift mechanism, 2 hydraulic cylinders, and 4 wheels support positioning and transport.
Year
2023
Country of manufacturing
Canada
General specifications
Dimensions
Width
Height
Length
Weight
3,759 mm
~148 in
4,013 mm
~158 in
25,195 mm
~991.9 in
3,130 kg
~6,900.5 lb
Capacity (bushels per hour)
11,000 bu/h
Recommended PTO Horsepower
160 hp
Tractor PTO RPM
540 PTO
Additional specifications
Drive type
PTO
HP Intake Diameter
330 mm
Height - Raised
16.84 mm
Reach - Lowered
13.131 mm
Reach - Raised
8.991 mm
Tube Thickness
12 ga
Flighting - Main
6.35 mm
1/4" Core Diameter
76.2 mm
Transport Length
29.195 mm
Transport Height
4.013 mm
Wheel Track Width
3.759 mm
Lower Bearing Size
44 mm
Gearbox Shaft Diameter
44 mm
Weight - Hitch
1.27 lb
Frame Arms
Fabricated
Undercarriage Axle
4.5"x4.5"x3/16"
Number of Hydraulic Cylinders
2
Hydraulic Requirements
1,100 psi
Tire Size
ST,235/85R16
Tire Ply Rating
8 Ply
Length x Width x Height
70"x 40"x10"
Height w/ Extension
431 mm
Number of Horizontal Flights
2
Number of Wheels
4
Hopper Wheel Size
254 mm
Lift Mechanism
Scissor
Brandt 1380XL Grain Auger Listings
Compare Brandt 1380XL Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
October 5, 2026
How to Choose the Right Excavator Bucket: Types, Sizes, and Contractor Buying Guide
This guide covers excavator bucket types, capacities, compatibility, and how to choose the right bucket for your jobsite.
September 28, 2026
Mini Excavator Buying Guide 2026: Best Models, Sizes and How to Choose
This guide breaks down everything you need to know about compact earthmoving equipment.
September 21, 2026
Types of Forklifts: Complete Guide to Classes, Uses, and Applications
This guide covers official forklift classes, physical machine variations, and load capacities.
August 25, 2026
Repair, Rebuild or Replace Heavy Equipment: 2026 Cost-Based Decision Guide
This guide provides a mathematical approach to help you decide what to do with your aging machinery in 2026.
July 31, 2026
How to Inspect Used Heavy Equipment Remotely: Practical Checklist for International Buyers
This article provides a practical, step-by-step guide for evaluating machinery without physical access.
July 10, 2026
New vs Used Heavy Equipment in 2026: Cost, Risk, ROI & When Each Option Wins
This guide explores new vs. used machinery investments, from costs and risks to financing and ROI.
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Brandt 1380XL?
No confirmed market price is supplied for the Brandt 1380XL. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Brandt 1380XL?
Listed features include capacity of 11,000 bu/h, 540 PTO operation, a scissor lift mechanism, two hydraulic cylinders, four wheels, and two horizontal flights. It also has an ST235/85R16, 8 Ply tire specification.
What type of engine does the 1380XL use?
The supplied data does not identify an engine for the 1380XL. It lists a 540 PTO requirement, indicating tractor PTO operation.
How much horsepower does the 1380XL have?
The 1380XL has a recommended PTO horsepower requirement of 119.3 kW (160 hp).
What fuel does the Brandt 1380XL use?
The supplied data does not confirm a fuel type for the Brandt 1380XL. It specifies 540 PTO operation rather than an onboard engine.
What jobs is this Grain Auger best suited for?
As a Grain Auger, the Brandt 1380XL is suited to grain-handling work. Its listed capacity is 11,000 bu/h, and it requires a tractor with 540 PTO and recommended PTO horsepower of 119.3 kW (160 hp).
What is the expected lifespan of the 1380XL?
The supplied data does not provide an expected service life for the 1380XL. Service life depends on operating conditions, maintenance, storage, and inspection of components such as flighting, bearings, tires, and hydraulic cylinders.
What should a buyer check when purchasing a used Grain Auger?
Check the flighting, tube, lower bearing, gearbox shaft, hydraulic cylinders, hoses, lift mechanism, frame arms, undercarriage axle, wheels, tires, hitch, and PTO connection. Operate the auger if possible and inspect for damage, wear, leaks, and abnormal noise.
