Mayrath HX2_1073 Grain Auger
Mayrath HX2_1073
5+
sold in last yearGeneral overview
Mayrath HX2_1073 is a grain auger built for grain handling and transfer in farm operations. It is set up for 540 RPM tractor PTO operation and is rated for 40 kW (55 hp), with a 254 mm (10 in) intake diameter to accept grain into the auger system.
Its handling range is defined by a height - raised of 14,700 mm (48 ft 3 in), a reach - lowered of 11,100 mm (36 ft 5 in), and a reach - raised of 9,200 mm (30 ft 2 in). The main auger uses 9" (22.9 cm) OD x 7 ga stretched and welded flighting with AR flighting at critical points, supported by 12 ga tube thickness and a 4" (10.2 cm) x 8" (20.3 cm) scissor lift.
Year
2023
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,438 mm
~96 in
4,000 mm
~157.5 in
22,250 mm
~876 in
2,270 kg
~5,004.5 lb
Capacity (bushels per hour)
6,000
Recommended PTO Horsepower
55 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
PTO
HP Intake Diameter
254 mm
Height - Raised
14,700 mm
Reach - Lowered
11,100 mm
Reach - Raised
9,200 mm
Tube Thickness
12 ga
Flighting - Main
9" (22.9 cm) OD x 7 ga stretched and welded with AR flighting at critical points
Transport Length
22.25 mm
Transport Height
4,000 mm
Wheel Track Width
3,350 mm
Undercarriage Axle
3" (7.6 cm) x 6" (15.2 cm) tubing
Tire Size
16" (40.6 cm) TRF
Lift Mechanism
4" (10.2 cm) x 8" (20.3 cm) scissor lift
