John Deere 5100MH Wheeled Tractors (High Crop)
John Deere 5100MH
5+
sold in last yearGeneral overview
John Deere 5100MH is a wheeled farm tractor designed for general agricultural work that requires drawbar pull, hitching, and hydraulic implement control. It is powered by a 100 kW (136 hp) diesel engine with 4.5 L (276 cu in) displacement and is listed with Interim Tier IV emissions compliance.
The model uses a SyncShuttle Plus transmission and an open center hydraulic system, with a rear hitch category of Cat-2. Rear lift capacity behind the lift points is 2,336 kg (5,150 lb), while the pump rated output is 93.5 L/min (24.7 gpm) and available flow at a single rear SCV is 69.6 L/min (18.4 gpm). It also has two rear selective control valves, mechanical or electrohydraulic SCV control, and lower-link sensing.
Year
2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,829 mm
~72 in
2,810 mm
~110.6 in
3,607 mm
~142 in
4,218 kg
~9,299.1 lb
Tire or Track Type
Wheels
Engine Power
100 hp
Ground Clearance
0.81 m
Additional specifications
Emission standard level
Interim Tier IV
Engine type
Diesel
Displacement
276 cu(in)
Tires front
230/95R40
Rated PTO power
63.4 hp
Speeds
540-2,100 rpm
Transmission type
SyncShuttle Plus
Rear hitch category (SAE designation)
Cat-2
Maximum lift capacity behind lift points
2,336 kg
Fuel tank
140 L
Hydraulic system type
Open center
Pump rated output
93.5 L/min
Available flow at a single rear SCV
69.6 L/min
Number of rear selective control valves
2
SCV control
Mechanical or electrohydraulic
Sensing type
Lower link
Tires rear
230/95R40
Transmission Speeds
