John Deere 260 Skid Steer / CTL
John Deere 260
5+
sold in last yearGeneral overview
The John Deere 260 is a skid steer loader designed for loading, material handling, and general construction-site work. It is powered by a John Deere 3029T engine with 2 L displacement and an output of 53 kW (72 hp). The model’s rated operating capacity is 1,089 kg (2,400 lb), which defines its lift class.
The 260 uses a hydrostatic (electronically controlled) powertrain with dual speed available and a maximum travel speed of 19 km/h (11.8 mph). Key working figures include a tipping load of 2,155 kg (4,750 lb), a dump height of 3,099 mm (10 ft 2 in), a height to top of ROPS of 2,105 mm (6 ft 11 in), loader flow of 125 L/min (33 gpm), and 213.8 bar (3,100 psi) at the couplers. These specifications support material handling and loading tasks where controlled lifting and travel speed are important.
Year
1999, 2000, 2001, 2002, 2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,505 mm
~138 in
2,134 mm
~84 in
1,930 mm
~76 in
Engine Power
72 hp
Operating Weight
2,435 kg
Rated Operating Capacity
1,089 kg
Dump Height
3,099 mm
Max. speed
19 km/h
Additional specifications
Displacement
2 cu(m)
Speeds
Dual speed available
Fuel tank
76 L
Wheelbase
1,219 mm
Axles
4 (skid steer configuration)
Battery Voltage
12
Net Power (ISO 9249)
69 hp
Manufacturer and Model
John Deere 3,029T
Alternator Rating
55
Pump flow loader
125 L/min
2 Speed High
19 km/h
System Pressure at Couplers
21,378 kPa
Length Without Bucket
3,048 mm
Length With Foundry Bucket
3,505 mm
Height to Top of ROPS
2,105 mm
Height to Hinge Pin
3,099 mm
Dump Reach With Foundry Bucket
813 mm
Ground Clearance
279 mm
Front Turn Radius With Foundry Bucket
2,127 mm
Dump Angle (full lift height)
45 deg
Bucket Rollback (ground level)
35 deg
Tipping Load
2,155 kg
SAE Rated Operating Capacity With Counterweight
1,180 kg
Boom Breakout Force With Foundry Bucket
21 kg
Boom Breakout Force With Construction Bucket
24 kg
Bucket Breakout Force With Foundry Bucket
28 kg
Bucket Breakout Force With Construction Bucket
30 kg
Powertrain Type
Hydrostatic (electronically controlled)
Operating Weight - Rear
3,742 kg
Standard features
14x17.5 SKS 12PR
Seed spacing
11 mm
Cylinders
3
John Deere 260 Skid Steer / CTL Listings
Looking for John Deere 260 Skid Steer / CTL?
See similar listingsCompare John Deere 260 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
October 5, 2026
How to Choose the Right Excavator Bucket: Types, Sizes, and Contractor Buying Guide
This guide covers excavator bucket types, capacities, compatibility, and how to choose the right bucket for your jobsite.
September 28, 2026
Mini Excavator Buying Guide 2026: Best Models, Sizes and How to Choose
This guide breaks down everything you need to know about compact earthmoving equipment.
September 21, 2026
Types of Forklifts: Complete Guide to Classes, Uses, and Applications
This guide covers official forklift classes, physical machine variations, and load capacities.
October 9, 2026
Motor Grader Buying Guide: Sizes, Top Brands, and What Contractors Should Look For
This guide helps buyers select the right motor grader for their needs and maximize ROI across construction, mining, and snow removal.
August 25, 2026
Repair, Rebuild or Replace Heavy Equipment: 2026 Cost-Based Decision Guide
This guide provides a mathematical approach to help you decide what to do with your aging machinery in 2026.
July 31, 2026
How to Inspect Used Heavy Equipment Remotely: Practical Checklist for International Buyers
This article provides a practical, step-by-step guide for evaluating machinery without physical access.
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 260?
No confirmed market price is supplied for the John Deere 260. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the John Deere 260?
Listed strengths include 1,089 kg (2,401 lb) rated operating capacity, 3,099 mm (122 in) dump height, hydrostatic electronically controlled powertrain, and 125 L/min (33 gpm) loader pump flow. Dual speed is available.
What type of engine does the 260 use?
The 260 uses a John Deere 3029T engine with 3 cylinders. The supplied specifications list 51.5 kW (69 hp) net power under ISO 9249.
How much horsepower does the 260 have?
The John Deere 260 is listed with 53.7 kW (72 hp) engine power. Its net power under ISO 9249 is 51.5 kW (69 hp).
What fuel does the John Deere 260 use?
The supplied specifications do not confirm the fuel type for the John Deere 260. They list a 76 L (20.1 US gal) fuel tank.
What jobs is this Skid Steer Loaders best suited for?
The supplied data does not specify particular jobs. Its listed capacity, dump height, hydrostatic powertrain, and loader hydraulic flow may be relevant when matching the machine to loading, material-handling, or attachment requirements.
What is the expected lifespan of the 260?
The supplied data does not provide an expected service life for the John Deere 260. For a used machine, inspect maintenance records, engine condition, hydraulic performance, tires, controls, and structural wear.
What should a buyer check when purchasing a used Skid Steer Loaders?
Check maintenance records, engine operation, hydrostatic drive response, hydraulic leaks and coupler pressure, loader and bucket wear, tire condition, ROPS condition, controls, and signs of structural damage. Confirm that operating capacity and attachment requirements match the intended work.
