John Deere 190GW Wheeled Excavators
John Deere 190GW
Average price
$244,695
5+
sold in last year
General overview
John Deere 190GW is an excavator designed for construction site digging and material movement. It is powered by an Isuzu 4HK1XASA13A engine rated at 127 kW (173 hp) and meets Tier 4 Final emission requirements. The machine has an operating weight of 19,700 kg (43,430 lb), giving it the mass needed for general excavation work.
Its working envelope includes a maximum digging depth of 5,830 mm (19 ft 2 in), maximum reach at ground level of 9,400 mm (30 ft 10 in), and maximum cutting height of 6,450 mm (21 ft 2 in). Hydraulic output is supported by a maximum rated flow of 236 L/min (62.3 gpm) and system relief pressure of 343 bar (4,970 psi), with bucket digging force of 126 kN (28,330 lbf) and stick digging force of 95 kN (21,360 lbf).
Year
2021, 2022, 2023
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
9,480 mm
~373.2 in
3,120 mm
~122.8 in
2,450 mm
~96.5 in
Engine Power
173 hp
Emission standard level
Tier 4 Final
Displacement
5 cu(m)
Fuel tank
290 L
Alternator output
50
Number of batteries
2
Cooling system
28 L
Number of Cylinders
4
Dimensions
mm
Width
2,450 mm
Operating Weight
19,700 kg
Reference Bucket Capacity
cu(m)
Drawbar Pull
93 kN
Maximum Rated Flow
236 L/min
System Relief Pressure
34,300 kPa
Hydraulic Pumps
cu(cm)
Hydraulic Capacity
100 L
Engine Model
Isuzu 4HK1XASA13A
Maximum Travel Speed - Low
8 km/h
Maximum Travel Speed - High
35 km/h
Maximum Pressure - Equipment
36,300 kPa
Maximum Pressure - Travel
34,800 kPa
Maximum Pressure - Swing
33,400 kPa
Battery Capacity
925
Engine Oil
23 L
Hydraulic System - Including Tank
180 L
Shipping Height - Top of Cab
3,220 mm
Handrail Height
2,200 mm
Tail Swing Radius
2,320 mm
Track Gauge
1,990 mm
Maximum Digging Depth
5,830 mm
Boom working ranges
mm
Stick working ranges
mm
Bucket working ranges
mm
Maximum Reach at Ground Level
9,400 mm
Maximum Cutting Height
6,450 mm
Maximum Loading Height
6,450 mm
Maximum Vertical Wall Digging Depth
5,260 mm
Bucket Digging Force - ISO
126 kN
Stick Digging Force - ISO
95 kN
Boom length
4,600 mm
Stick length
2,710 mm
Net Power (ISO 9249)
173 hp
Hydraulic Pump
1 gear
Maximum Operating Pressure
34,300 kPa
Additional specifications
Rated power
129 kW
Axles
-
Header
-
Ground Pressure
kPa
Additional Options
-
