John Deere 184 G-Tier Wheel Loaders
John Deere 184 G-Tier
5+
sold in last yearGeneral overview
The John Deere 184 G-Tier is a wheel loader built for loading, material handling, and general construction work. It is powered by a Yanmar 4TNV88C engine rated at 32 kW (44 hp) and has an operating weight of 4,840 kg (10,670 lb), placing it in a compact loader class for confined jobsite work.
The machine is equipped with a 0.7 m³ (0.9 cu yd) general purpose bucket and meets EPA Final Tier 4 / EU Stage V emissions standards. Its 2.15 m (7 ft 1 in) wheelbase, 19 km/h (11.8 mph) travel speed, and 80° articulation angle support maneuverability. Hydraulic functions include a 61 L/min (16.1 gpm) 3rd auxiliary flow, with dump, lift, and lower/float cycle times of 1.3 s, 4.6 s, and 3 s.
Year
2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,780 mm
~70.1 in
3,160 mm
~124.4 in
5,420 mm
~213.4 in
4,840 kg
~10,670.4 lb
Engine Power
44 hp
Operating Weight
4,840 kg
Bucket Capacity
0.7 cu(m)
Additional specifications
Emission standard level
EPA Final Tier 4 / EU Stage V
Displacement
134 cu(in)
Fuel tank
62 L
Electrical system type
12 V
Number of batteries
830 CCA
Cooling system
10 L
Wheelbase
2.15 m
Number of Cylinders
4
Ground clearance with standard tires
0.292 m
System Relief Pressure
3.336 kPa
Engine Model
Yanmar 4TNV88C
Engine Oil
7.4 L
Power - Net
44 hp
Net Power (ISO 9249)
44 hp
General Purpose
0.7 cu(m)
3rd Auxiliary Flow
61 L/min
Hydraulic Cycle Time - Lower, Float
3 m
Travel Speeds
19 km/h
Hydraulic Cycle Time - Lift
4.6 m
Hydraulic Cycle Time - Dump
1.3 m
Overall Length - With Bucket
5.42 m
Reach at Maximum Dump Height
0.859 m
Dig Depth
0.8 m
Maximum Dump Height
1.58 m
Hinge Pin at Maximum Height
3.16 m
Overall Length - With Forks
5.42 m
Maximum Reach
1.58 m
Fork Height at Maximum Reach
1.31 m
Maximum Fork Height
2.97 m
Turning Radius - Over Bucket
4.33 m
Width - Over Bucket
1.78 m
Articulation Angle
80 deg
Hydraulic System
45 L
Cab Height
2.45 m
Rated Operating Capacity
1,300 kg
John Deere 184 G-Tier Wheel Loaders Listings
Looking for John Deere 184 G-Tier Wheel Loaders?
See similar listingsCompare John Deere 184 G-Tier Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
John Deere 184 G-Tier Wheel Loader
0.7 cu(m)
4840 kg
5420 mm × 1780 mm × 3160 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a John Deere 184 G-Tier?
No confirmed market price is supplied for the John Deere 184 G-Tier. Check current listings and compare machine condition, location, configuration, and included attachments.
What are the key advantages of the John Deere 184 G-Tier?
Listed strengths include a 0.7 m³ (0.92 cu yd) general-purpose bucket, 32.8 kW (44 hp) net power, 19 km/h (11.8 mph) travel speed, 80° articulation angle, and available fork-related lift and reach specifications. It also has 3rd auxiliary flow of 61 L/min (16.1 gpm).
What type of engine does the 184 G-Tier use?
The 184 G-Tier uses a Yanmar 4TNV88C engine with 4 cylinders. Its listed displacement is 134 cu in, and it meets EPA Final Tier 4 / EU Stage V emissions requirements.
How much horsepower does the 184 G-Tier have?
The 184 G-Tier has 32.8 kW (44 hp) net power, including Net Power (ISO 9249).
What fuel does the John Deere 184 G-Tier use?
The supplied specifications do not confirm the fuel type for the John Deere 184 G-Tier. They list a fuel tank capacity of 62 L (16.4 US gal).
What jobs is this Wheel Loaders best suited for?
The supplied data does not specify particular applications. The machine has a 0.7 m³ (0.92 cu yd) bucket and listed fork height and reach specifications, so buyers should confirm that its attachment setup, lift requirements, and site dimensions suit the intended work.
What is the expected lifespan of the 184 G-Tier?
No expected service-life figure is supplied for the 184 G-Tier. For a used machine, assess maintenance records, operating condition, hydraulic performance, engine condition, tires, articulation joints, and attachment wear.
What should a buyer check when purchasing a used Wheel Loaders?
Check service records, engine starting and operation, hydraulic leaks and cycle performance, bucket and fork wear, tires, articulation joints, steering, brakes, electrical system, cooling system, and signs of structural damage. Verify that included attachments and configuration match the intended work.
