Hyundai HL770-9A Wheel Loaders
Hyundai HL770-9A
5+
sold in last yearGeneral overview
Hyundai HL770-9A is a wheel loader designed for loading, moving, and handling bulk materials in construction and related site work. It combines an operating weight of 23,100 kg (50,930 lb) with a heaped bucket capacity of 4 m³ (5.2 cu yd), placing it in a medium-to-large loader class for material handling and earthmoving support.
The machine is powered by the HE 8.9 six-cylinder engine, with engine power of 218 kW (297 hp) and Tier 3 emissions compliance. It travels forward at 41 km/h (25.5 mph) and has a width of 3,100 mm (10 ft 2 in), a wheelbase of 3,500 mm (11 ft 6 in), and a height to top of cab of 3,560 mm (11 ft 8 in). At maximum height, the hinge pin reaches 4,310 mm (14 ft 2 in), with a load over height of 3,090 mm (10 ft 2 in) and a reach at maximum dump height of 1,295 mm (4 ft 3 in).
Year
2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
Korea, Republic of
General specifications
Dimensions
Length
Height
Width
8,700 mm
~342.5 in
3,560 mm
~140.2 in
3,100 mm
~122 in
Engine Power
297 hp
Operating Weight
23,100 kg
Bucket Capacity
4.2 cu(m)
Bucket Capacity - Heaped
4 cu(m)
Additional specifications
Emission standard level
Tier 3
Fuel tank
390 L
Height to top of cab
3,560 mm
Wheelbase
3,500 mm
Number of Cylinders
6
Ground clearance with standard tires
480 mm
Width
3,100 mm
Travel Speed Forward
41 km/h
Engine Model
HE 8.9
Engine Oil
23 L
Power - Net
277 hp
Net Power (ISO 9249)
297 hp
General Purpose
4 cu(m)
Light Material
4 cu(m)
3rd Auxiliary Flow
342 L/min
Hydraulic Cycle Time - Lift
5 s
Hydraulic Cycle Time - Dump
1 s
Overall Length - With Bucket
8,700 mm
Reach at Maximum Dump Height
1,295 mm
Load Over Height
3,090 mm
Hinge Pin at Maximum Height
4,310 mm
Width - Over Bucket
3,100 mm
Dump Angle at Maximum Height
45 deg
Hydraulic System
200 L
Rated Operating Capacity
15,350 kg
Hyundai HL770-9A Wheel Loaders Listings
Looking for Hyundai HL770-9A Wheel Loaders?
See similar listingsCompare Hyundai HL770-9A Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
October 5, 2026
How to Choose the Right Excavator Bucket: Types, Sizes, and Contractor Buying Guide
This guide covers excavator bucket types, capacities, compatibility, and how to choose the right bucket for your jobsite.
September 28, 2026
Mini Excavator Buying Guide 2026: Best Models, Sizes and How to Choose
This guide breaks down everything you need to know about compact earthmoving equipment.
September 21, 2026
Types of Forklifts: Complete Guide to Classes, Uses, and Applications
This guide covers official forklift classes, physical machine variations, and load capacities.
October 9, 2026
Motor Grader Buying Guide: Sizes, Top Brands, and What Contractors Should Look For
This guide helps buyers select the right motor grader for their needs and maximize ROI across construction, mining, and snow removal.
August 25, 2026
Repair, Rebuild or Replace Heavy Equipment: 2026 Cost-Based Decision Guide
This guide provides a mathematical approach to help you decide what to do with your aging machinery in 2026.
July 31, 2026
How to Inspect Used Heavy Equipment Remotely: Practical Checklist for International Buyers
This article provides a practical, step-by-step guide for evaluating machinery without physical access.
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Hyundai HL770-9A?
No confirmed market price is supplied for the Hyundai HL770-9A. Check current listings and compare machine condition, location, configuration, service records, and included attachments.
What are the key advantages of the Hyundai HL770-9A?
Listed strengths include a 4 m³ (5.23 cu yd) heaped bucket capacity, 221.5 kW (297 hp) engine power, 23,100 kg (50,927 lb) operating weight, and a 41 km/h (25.5 mph) forward travel speed. Hydraulic lift and dump times are listed as 5 s and 1 s.
What type of engine does the HL770-9A use?
The HL770-9A is listed with a HE 8.9 engine. The supplied specifications identify 6 cylinders and a Tier 3 emission standard level.
How much horsepower does the HL770-9A have?
The HL770-9A has listed engine power of 221.5 kW (297 hp). Its listed net power is 206.6 kW (277 hp), while Net Power (ISO 9249) is listed as 221.5 kW (297 hp).
What fuel does the Hyundai HL770-9A use?
The supplied information does not confirm the fuel type for the Hyundai HL770-9A. It lists a fuel tank capacity of 390 L (103 US gal), but not the fuel specification.
What jobs is this Wheel Loaders best suited for?
The supplied specifications support its use for material loading and handling with a 4 m³ (5.23 cu yd) general-purpose or light-material bucket. Application suitability should also be confirmed against the required material type, site conditions, attachments, and local operating requirements.
What is the expected lifespan of the HL770-9A?
The supplied data does not provide an expected service-life estimate for the HL770-9A. For a used machine, review maintenance records, operating hours, engine condition, hydraulic performance, tires, bucket linkage, and signs of structural wear.
What should a buyer check when purchasing a used Wheel Loaders?
Check service records, operating hours, engine starting and running condition, hydraulic lift and dump performance, leaks, tire condition, articulation joint wear, bucket and linkage wear, cab controls, and structural damage. Confirm the machine’s configuration, attachments, and emission requirements for the intended site.
