Caterpillar 420F2 IT Backhoe Loaders
Caterpillar 420F2 IT
5+
sold in last yearGeneral overview
Caterpillar 420F2 IT is a backhoe loader designed for digging, loading, and general construction site work. It is powered by a Cat C4.4 ACERT engine with 4 cylinders and 4 L displacement, and it has an operating weight of 11,000 kg (24,250 lb). The model is listed for 2015 production and manufactured in the United States.
Its AutoShift Power Shuttle transmission and 4,360 mm (14 ft 4 in) dig depth define the machine’s backhoe side performance, while the 180° swing arc and closed center controls support coordinated digging and loading work. The engine meets Tier 4 Final emissions requirements, and the backhoe and loader circuits each use 163 L/min (43.1 gpm) pump flow with 250 bar (3,630 psi) system relief pressure.
Year
2015
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
7,170 mm
~282.3 in
3,580 mm
~140.9 in
2,320 mm
~91.3 in
Engine Power
93 hp
Operating Weight
11,000 kg
Dig Depth
4,360 mm
Capacity Bucket (loader)
cu(m)
Capacity Bucket (backhoe)
cu(m)
Digging Depth (SAE)
4.36 m
Additional specifications
Emission standard level
Tier 4 Final
Displacement
4 cu(m)
Tires front
11L-16 (12 ply) F-3
Transmission type
AutoShift Power Shuttle
Fuel tank
160 L
Cooling system
22 L
Overall length w/header
7,170 mm
Height to top of cab
3,580 mm
Wheelbase
2,200 mm
Number of Cylinders
4
Tires rear
19.5L-24 (12 ply) R4 ATU
Ground clearance with standard tires
294 mm
Battery Voltage
12
Bucket Width
610 mm
Hydraulic Capacity
95 L
Engine Model
Cat C4.4 ACERT
Engine Oil
8 L
Maximum Digging Depth
105 mm
Power - Net
93 hp
Net Power (ISO 9249)
94 hp
Alternator Rating
120
Bucket Weight
141 kg
Bucket Range
2,260 mm
Swing Arc
180 deg
Pump flow backhoe
163 L/min
Pump flow loader
163 L/min
System Relief Pressure backhoe
25,000 kPa
System Relief Pressure loader
25,000 kPa
Controls backhoe
Closed Center
Controls loader
Closed Center
Lights
6–8 work lights + road lights
Operating Weights with Full Fuel Tank, Standard Equipment
11,000 kg
Operating Weights typical with Cab, Extendable Dipperstick and Counterweight
7,726 kg
Length From Axle to Axle
2,200 mm
Loading Height, Truck Loading Position
3,642 mm
Reach From Center of Swing Pivot
5,610 mm
Digging Depth (SAE maximum)
5,441 mm
Stabilizer Spread, Operating
3,310 mm
Stabilizer Overall Width, Operating
3,770 mm
Bucket Dump Angle, Maximum
44 deg
Rollback Angle at Ground Level
40 deg
Height to Bucket Hinge Pin, Maximum
3,490 mm
Reach at Full Height, Bucket at 45 deg.
869 mm
Length From Front Axle Centerline to Bucket Cutting Edge
2,200 mm
Main Pump Type
Variable Flow, Axial Piston
Rated Operating Capacity
3,283 kg
Caterpillar 420F2 IT Backhoe Loaders Listings
Looking for Caterpillar 420F2 IT Backhoe Loaders?
See similar listingsCompare Caterpillar 420F2 IT Backhoe Loader to other backhoe loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Caterpillar 420F2 IT Backhoe Loader
4360 mm
7170 mm × 2320 mm × 3580 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
October 5, 2026
How to Choose the Right Excavator Bucket: Types, Sizes, and Contractor Buying Guide
This guide covers excavator bucket types, capacities, compatibility, and how to choose the right bucket for your jobsite.
September 28, 2026
Mini Excavator Buying Guide 2026: Best Models, Sizes and How to Choose
This guide breaks down everything you need to know about compact earthmoving equipment.
September 21, 2026
Types of Forklifts: Complete Guide to Classes, Uses, and Applications
This guide covers official forklift classes, physical machine variations, and load capacities.
October 9, 2026
Motor Grader Buying Guide: Sizes, Top Brands, and What Contractors Should Look For
This guide helps buyers select the right motor grader for their needs and maximize ROI across construction, mining, and snow removal.
August 25, 2026
Repair, Rebuild or Replace Heavy Equipment: 2026 Cost-Based Decision Guide
This guide provides a mathematical approach to help you decide what to do with your aging machinery in 2026.
July 31, 2026
How to Inspect Used Heavy Equipment Remotely: Practical Checklist for International Buyers
This article provides a practical, step-by-step guide for evaluating machinery without physical access.
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Caterpillar 420F2 IT?
No confirmed market price is supplied. Check current listings and compare machine condition, location, configuration, service records, and included attachments.
What are the key advantages of the Caterpillar 420F2 IT?
Listed features include 69.4 kW (93 hp) engine power, AutoShift Power Shuttle transmission, Closed Center controls, and Variable Flow, Axial Piston hydraulics. The backhoe has a 180° swing arc and 5,441 mm (214.2 in) SAE maximum digging depth.
What type of engine does the 420F2 IT use?
The 420F2 IT uses a Cat C4.4 ACERT engine. The supplied specification lists Tier 4 Final emissions level and 4 cylinders.
How much horsepower does the 420F2 IT have?
The listed engine power is 69.4 kW (93 hp). Net Power (ISO 9249) is listed separately as 70.1 kW (94 hp).
What fuel does the Caterpillar 420F2 IT use?
The supplied data does not confirm the fuel type. It lists a fuel tank capacity of 160 L (42.3 US gal).
What jobs is this Backhoe Loaders best suited for?
The supplied specifications do not confirm intended job applications. Its listed backhoe capabilities include 5,441 mm (214.2 in) SAE maximum digging depth, 5,610 mm (220.9 in) reach from the swing pivot, and a 180° swing arc.
What is the expected lifespan of the 420F2 IT?
No expected service-life estimate is supplied. For a used machine, assess maintenance history, operating hours, hydraulic performance, engine condition, transmission operation, tires, and structural wear.
What should a buyer check when purchasing a used Backhoe Loaders?
Check service records, engine starting and operation, hydraulic leaks and function, backhoe and loader controls, transmission shifting, tire condition, bucket and linkage wear, stabilizers, lights, and signs of frame or cab damage. Verify that the machine’s configuration matches the listing.
