Caterpillar 289D Skid Steer / CTL
Caterpillar 289D
5+
sold in last yearGeneral overview
Caterpillar 289D is a skid steer loader used for loading, lifting, and material handling in construction settings. It is powered by a Cat C3.3B DIT (turbo) engine rated at 54 kW (73.7 hp) and has a rated operating capacity of 1,837 kg (4,050 lb), placing it in a mid-size class for general jobsite work.
The 289D uses a hydrostatic transmission with planetary final drive system and hydrostatic braking system. Travel speed reaches 11.3 km/h (7 mph) in 2 Speed High, and the hydraulic system provides 86 L/min (22.7 gpm) at 241.3 bar (3,500 psi). Operating weight is 4,709 kg (10,380 lb), and the bucket specifications include 0.48 m³ (0.6 cu yd) capacity and 2,858 kg (6,300 lb) bucket breakout force with Construction Bucket.
Year
2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
1,900 mm
~74.8 in
2,100 mm
~82.7 in
3,700 mm
~145.7 in
4,778 kg
~10,533.7 lb
Engine Power
73.7 hp
Operating Weight
4,778 kg
Rated Operating Capacity
1,837 kg
Dump Height
0.761 m
Bucket volume
0.48 cu(m)
Max. speed
11.3 km/h
Additional specifications
Emission standard level
Tier 4 f
Displacement
201 cu(in)
Base machine weight
4,709 kg
Fuel tank
94 L
Number of batteries
2
Wheelbase
1.5 m
Number of Cylinders
6
Battery Voltage
12V
Tires
12 x 16.5
Battery Capacity
850 CCA
Net Power (ISO 9249)
73.7 hp
Manufacturer and Model
Cat C3.3B DIT (turbo)
Pump Flow
86 L/min
Alternator Rating
80 amps
Single
7.2 km/h
2 Speed High
11.3 km/h
Tractive Effort
8.8 Nm
Final Drive
planetary final drive system
Brakes
hydrostatic braking system
System Pressure at Couplers
24,130 kPa
Hydraulic Horsepower Flow
73.2 hp
Length Without Bucket
2.9 m
Length With Foundry Bucket
3.7 m
Width Without Bucket
2.01 m
Height to Top of ROPS
2.66 m
Height to Hinge Pin
3.18 m
Dump Height With Foundry Bucket
2.98 m
Dump Reach
1.3 m
Dump Reach With Foundry Bucket
1.3 m
Dump Reach With Construction Bucket
1.3 m
Ground Clearance
0.226 m
Angle of Departure
33°
Front Turn Radius With Foundry Bucket
2 m
Dump Angle (full lift height)
51°
Bucket Rollback (ground level)
30°
Tipping Load
3,447 kg
SAE Rated Operating Capacity With Counterweight
1,224 kg
Boom Breakout Force With Foundry Bucket
2,744 kg
Boom Breakout Force With Construction Bucket
2,744 kg
Bucket Breakout Force With Foundry Bucket
2,858 kg
Bucket Breakout Force With Construction Bucket
2,858 kg
Powertrain Type
Hydrostatic Transmission
Caterpillar 289D Skid Steer / CTL Listings
Looking for Caterpillar 289D Skid Steer / CTL?
See similar listingsCompare Caterpillar 289D Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Caterpillar 289D Skid Steer / CTL
0.48 cu(m)
4778 kg
3700 mm × 1900 mm × 2100 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
October 5, 2026
How to Choose the Right Excavator Bucket: Types, Sizes, and Contractor Buying Guide
This guide covers excavator bucket types, capacities, compatibility, and how to choose the right bucket for your jobsite.
September 28, 2026
Mini Excavator Buying Guide 2026: Best Models, Sizes and How to Choose
This guide breaks down everything you need to know about compact earthmoving equipment.
September 21, 2026
Types of Forklifts: Complete Guide to Classes, Uses, and Applications
This guide covers official forklift classes, physical machine variations, and load capacities.
October 9, 2026
Motor Grader Buying Guide: Sizes, Top Brands, and What Contractors Should Look For
This guide helps buyers select the right motor grader for their needs and maximize ROI across construction, mining, and snow removal.
August 25, 2026
Repair, Rebuild or Replace Heavy Equipment: 2026 Cost-Based Decision Guide
This guide provides a mathematical approach to help you decide what to do with your aging machinery in 2026.
July 31, 2026
How to Inspect Used Heavy Equipment Remotely: Practical Checklist for International Buyers
This article provides a practical, step-by-step guide for evaluating machinery without physical access.
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Caterpillar 289D?
No confirmed market price is supplied. Check current listings and compare machine condition, location, hours, attachments, and configuration.
What are the key advantages of the Caterpillar 289D?
Listed strengths include 55 kW (73.7 hp) of engine power, a rated operating capacity of 1,837 kg (4,050 lb), hydrostatic transmission, two-speed travel, and hydraulic flow of 86 L/min (22.7 gpm). It also has a planetary final drive system and hydrostatic braking system.
What type of engine does the 289D use?
The 289D uses a Cat C3.3B DIT (turbo) engine. The supplied specification lists Tier 4 f emissions, 6 cylinders, and 201 cu in displacement.
How much horsepower does the 289D have?
The 289D is rated at 55 kW (73.7 hp) of engine power. Net Power (ISO 9249) is also listed as 55 kW (73.7 hp).
What fuel does the Caterpillar 289D use?
The supplied specifications do not confirm the fuel type. They list a fuel tank capacity of 94 L (24.8 US gal), but do not identify the fuel.
What jobs is this Skid Steer Loaders best suited for?
Its listed capacity, bucket volume, hydraulic flow, and breakout forces indicate suitability for material loading, digging, grading, and attachment-based work. Confirm the bucket or attachment, operating capacity, site access, and hydraulic requirements for the intended job.
What is the expected lifespan of the 289D?
The supplied data does not provide an expected service-life estimate. For a used machine, service life depends on maintenance history, operating conditions, hydraulic condition, engine condition, undercarriage wear, and prior workload.
What should a buyer check when purchasing a used Skid Steer Loaders?
Check service records, engine starting and operation, hydraulic leaks and coupler pressure, pump performance, drive system operation, brakes, tire condition, bucket and attachment wear, ROPS condition, battery system, and signs of structural repairs. Test all controls under load where possible.
