Caterpillar 236D3 Skid Steer / CTL
Caterpillar 236D3
5+
sold in last yearGeneral overview
Caterpillar 236D3 is a skid steer loader designed for construction material handling, site work, and loading tasks. It is rated at 54 kW (74 hp) and has an operating weight of 2,978 kg (6,570 lb), placing it in a compact loader class suitable for jobsite work.
The model uses a hydrostatic powertrain with a fixed axle skid steer design and hydrostatic dynamic braking. It has a rated operating capacity of 818 kg (1,800 lb), or 910 kg (2,010 lb) with counterweight, and a maximum speed of 17 km/h (10.6 mph) with the optional two-speed arrangement. It is powered by a 4-cylinder, 3 L engine and meets U.S. EPA Tier 4 Final / EU Stage V emissions standards. Key dimensions include a width without bucket of 1,500 mm (4 ft 11 in) and a dump height of 2,360 mm (7 ft 9 in).
Year
2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
3,487 mm
~137.3 in
1,990 mm
~78.3 in
1,720 mm
~67.7 in
Engine Power
74 hp
Operating Weight
2,979 kg
Rated Operating Capacity
818 kg
Dump Height
2,360 mm
Bucket volume
400 cu(m)
Max. speed
17 km/h
Additional specifications
Emission standard level
U.S. EPA Tier 4 Final / EU Stage V
Displacement
3 cu(m)
Speeds
One or two speed (optional)
Fuel tank
78 L
Number of batteries
2
Wheelbase
1,105 mm
Axles
Fixed axle skid steer design
Battery Voltage
12
Final drive
Hydrostatic
Battery Capacity
100
Net Power (ISO 9249)
73 hp
Manufacturer and Model
Cat C3.3B DIT (turbo) / Cat C2.2 (turbo)
Alternator Rating
100
Pump flow loader
76 L/min
2 Speed High
17 km/h
Brakes
Hydrostatic dynamic braking
System Pressure at Couplers
23,000 kPa
Hydraulic Horsepower Flow
39 hp
Length Without Bucket
2,767 mm
Length With Foundry Bucket
3,487 mm
Width Without Bucket
1,500 mm
Height to Top of ROPS
1,990 mm
Height to Hinge Pin
3,125 mm
Dump Height With Foundry Bucket
2,455 mm
Dump Reach With Foundry Bucket
745 mm
Ground Clearance
195 mm
Front Turn Radius With Foundry Bucket
2,110 mm
Dump Angle (full lift height)
52 deg
Bucket Rollback (ground level)
35 deg
Tipping Load
1,635 kg
SAE Rated Operating Capacity With Counterweight
910 kg
Boom Breakout Force With Foundry Bucket
25 kg
Bucket Breakout Force With Foundry Bucket
44 kg
Bucket Breakout Force With Construction Bucket
22 kg
Powertrain Type
Hydrostatic
Operating Weight - Rear
2,978 kg
Standard features
10x16.5
Seed spacing
11 mm
Cylinders
4
