Case 580SN Backhoe Loaders
Case 580SN
5+
sold in last yearGeneral overview
The Case 580SN is a backhoe loader produced from 2017 to 2024 in the United States for construction-site digging, loading, and material handling. It combines a 70 kW (95 hp) engine with an operating weight of 8,078 kg (17,810 lb), giving it the power and mass typical of a utility backhoe loader used for mixed earthmoving work.
It is offered with a powershuttle transmission as standard, with powershift optional, and uses a variable displacement axial piston pump. Hydraulic output is listed at 156 L/min (41.2 gpm) for both the backhoe and loader circuits. The machine’s working envelope includes a dig depth of 4,410 mm (14 ft 6 in), an SAE maximum digging depth of 5,470 mm (17 ft 11 in), and a truck loading height of 3,670 mm (12 ft).
Year
2017, 2024
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
7,140 mm
~281.1 in
2,680 mm
~105.5 in
2,170 mm
~85.4 in
Engine Power
95 hp
Operating Weight
8,078 kg
Dig Depth
4,410 mm
Capacity Bucket (loader)
cu(m)
Capacity Bucket (backhoe)
cu(m)
Digging Depth (SAE)
4.41 m
Additional specifications
Tires front
11L x 16 (2WD) / 12L x 16.5 (4WD)
Transmission type
Powershuttle (standard) / Powershift (optional)
Fuel tank
159 L
Cooling system
18 L
Overall length w/header
7,140 mm
Height to top of cab
2,680 mm
Wheelbase
2,130 mm
Number of Cylinders
4
Tires rear
19.5L x 24 (common) / 17.5L x 24 (option)
Ground clearance with standard tires
304 mm
Battery Voltage
12
Bucket Width
762 mm
Hydraulic Capacity
119 L
Engine Oil
13 L
Maximum Digging Depth
155 mm
Power - Net
95 hp
Net Power (ISO 9249)
95 hp
Alternator Rating
160
Bucket Weight
222 kg
Bucket Range
2,080 mm
Pump flow backhoe
156 L/min
Pump flow loader
156 L/min
System Relief Pressure backhoe
23,787 kPa
System Relief Pressure loader
24,993 kPa
Controls backhoe
Pilot controls (left-hand joystick) / cab floor pedal for some functions
Lights
4x front + 2x side + 4x rear adjustable halogen work lights (55 W)
Operating Weights with Full Fuel Tank, Standard Equipment
8,078 kg
Length From Axle to Axle
2,130 mm
Loading Height, Truck Loading Position
3,670 mm
Reach From Center of Swing Pivot
5,550 mm
Digging Depth (SAE maximum)
5,470 mm
Stabilizer Spread, Operating
2,820 mm
Stabilizer Overall Width, Operating
2,930 mm
Bucket Dump Angle, Maximum
47 deg
Rollback Angle at Ground Level
42 deg
Height to Bucket Hinge Pin, Maximum
3,420 mm
Reach at Full Height, Bucket at 45 deg.
801 mm
Length From Front Axle Centerline to Bucket Cutting Edge
2,070 mm
Dump Clearance
2,690 mm
Main Pump Type
Variable Displacement Axial Piston Pump (Bosch Rexroth Series 31)
Rated Operating Capacity
3,721 kg
