Case IH 9010 Combines
Case IH 9010
Average price
$81,000
5+
sold in last year
General overview
Case IH 9010 is a combine harvester built for farm harvesting operations. Produced for the 2007 and 2008 model years, it uses a diesel engine with rated power of 400 kW (544 hp) and engine power of 450 kW (612 hp), placing it in a high-output class for large-scale crop work.
This model is configured with wheel propulsion and a Tier 3 emission standard level. It also features a rotary AFX separator, a threshing area wrap of 180°, and a sieve area of 6.6 m² (71 sq ft). For crop handling, it has a grain tank size of 11,629 L (3,072 US gal) and a peak unloading rate of 106 L/s (3 bu/s), supporting extended harvest cycles in the field.
Year
2007, 2008
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
4,200 mm
~165.4 in
4,020 mm
~158.3 in
6,400 mm
~252 in
16,488 kg
~36,349.8 lb
Engine Power
450 hp
Emission standard level
Tier 3
Grain tank size
11,629 L
Peak unloading rate
106 L/sec
Additional specifications
Engine type
Diesel
Displacement
628 cu(in)
Fuel tank
1,000 L
Type of propulsion
Wheel
Separator type
Rotary AFX
Threshing Area Wrap
180 deg
Sieve area
6.6 sq(m)
Unloading auger length
5.49 m
Unloading rate
106 L/sec
Rated power
400 hp
Case IH 9010 Combines Listings
$81,000
1000 L
180 deg
6.6 sq(m)
2344 hours
Overland Park, United States
Compare Case IH 9010 Combine to other combines
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH 9010?
No confirmed market price is supplied for the Case IH 9010. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Case IH 9010?
Listed features include a Rotary AFX separator, 11,629 L grain tank, 106 L/s unloading rate, 6.6 m² sieve area, and wheel propulsion. It has a Diesel engine rated at 298.3 kW (400 hp), with engine power of 335.6 kW (450 hp).
What type of engine does the 9010 use?
The 9010 uses a Diesel engine with 628 cu in displacement and Tier 3 emissions level.
How much horsepower does the 9010 have?
The 9010 has rated power of 298.3 kW (400 hp). Its listed engine power is 335.6 kW (450 hp).
What fuel does the Case IH 9010 use?
The Case IH 9010 uses Diesel fuel. Its fuel tank capacity is 1,000 L (264.2 US gal).
What jobs is this Combines best suited for?
The Case IH 9010 is a combine for harvesting operations. The supplied information does not specify particular crops or field conditions for which it is best suited.
What is the expected lifespan of the 9010?
The supplied data does not confirm an expected service life for the 9010. Inspect maintenance records, operating condition, and wear on major harvesting and unloading components when assessing a used machine.
What should a buyer check when purchasing a used Combines?
Check maintenance records, engine condition, fuel system, grain tank, unloading auger, separator, sieve area, wheel propulsion, and signs of wear or damage. Verify that unloading functions operate correctly and inspect the machine in person where possible.
