Case IH 8230 Combines
Case IH 8230
Average price
$69,500
5+
sold in last year
General overview
Case IH 8230 is a combine harvester designed for field grain harvesting, threshing, and crop separation. Produced from 2012 to 2014, it uses a diesel engine and is listed with Tier 4A (Interim) emissions compliance. The model is built as a wheeled machine for crop harvest operations where cutting, threshing, and grain collection are carried out in a single pass.
Its power rating is 450 kW (612 hp), with engine power listed at 510 kW (694 hp), and the engine displacement is 12.9 L. The combine uses a longitudinal rotor separator and a 180° threshing area wrap, with a sieve area of 6.5 m² (70 sq ft). Grain storage capacity is 12,334 L (3,258 US gal), and unloading is specified at 141 L/s (4 bu/s).
Year
2012, 2013, 2014
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,750 mm
~147.6 in
3,910 mm
~153.9 in
8,550 mm
~336.6 in
17,006 kg
~37,491.8 lb
Engine Power
510 hp
Emission standard level
Tier 4A (Interim)
Grain tank size
12,334 L
Peak unloading rate
141 L/sec
Additional specifications
Engine type
Diesel
Displacement
787 cu(in)
Fuel tank
1,000 L
Type of propulsion
Wheel
Separator type
Longitudinal rotor
Threshing Area Wrap
180 deg
Sieve area
6.5 sq(m)
Unloading auger length
8.76 m
Unloading rate
141 L/sec
Rated power
450 hp
Case IH 8230 Combines Listings
Compare Case IH 8230 Combine to other combines
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH 8230?
No confirmed market price is supplied. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Case IH 8230?
Supplied specifications include a longitudinal rotor separator, 12,334 L grain tank, 141 L/s unloading rate, 6.5 m² sieve area, and wheel propulsion. These features describe its harvesting and grain-handling configuration.
What type of engine does the 8230 use?
The Case IH 8230 uses a Diesel engine with 787 cu in displacement and Tier 4A (Interim) emissions standard level.
How much horsepower does the 8230 have?
The Case IH 8230 has 510 hp engine power and 450 hp rated power.
What fuel does the Case IH 8230 use?
The Case IH 8230 uses Diesel fuel.
What jobs is this Combines best suited for?
The supplied data identifies the Case IH 8230 as a combine with a longitudinal rotor separator, wheel propulsion, grain tank, and unloading system. It is suited to combine harvesting work, though the supplied information does not confirm specific crop suitability.
What is the expected lifespan of the 8230?
The supplied data does not provide an expected service life. Evaluate maintenance records, operating hours, wear in threshing and separation components, engine condition, and the unloading system when assessing an individual machine.
What should a buyer check when purchasing a used Combines?
Check maintenance records, operating hours, engine condition, rotor and threshing components, sieve area, grain tank, unloading auger, tires, and hydraulic or electrical functions. Test the unloading system and inspect for wear, leaks, damage, and missing guards.
