Case IH 7230 Combines
Case IH 7230
Average price
$69,900
5+
sold in last year
General overview
Case IH 7230 is a combine harvester produced for field crop harvesting. It is designed to cut, thresh, separate, and collect grain in a single machine, and it uses a wheel type of propulsion for field mobility. Key specifications include a Diesel engine, 8.7 L displacement, and an engine power of 440 kW (598 hp).
The model is fitted with Tier 4A (Interim) emissions compliance, a longitudinal rotor separator, and a threshing area wrap of 180°. Its grain tank size is 11,100 L (2,932 US gal), with a peak unloading rate of 141 L/s (4 bu/s). The sieve area is 6.5 m² (70 sq ft), supporting high-capacity harvesting and grain handling in demanding crop operations.
Year
2012, 2013, 2014
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,700 mm
~145.7 in
3,910 mm
~153.9 in
8,400 mm
~330.7 in
16,692 kg
~36,799.6 lb
Engine Power
440 hp
Emission standard level
Tier 4A (Interim)
Grain tank size
11,100 L
Peak unloading rate
141 L/sec
Additional specifications
Engine type
Diesel
Displacement
531 cu(in)
Fuel tank
1,000 L
Type of propulsion
Wheel
Separator type
Longitudinal rotor
Threshing Area Wrap
180 deg
Sieve area
6.5 sq(m)
Unloading auger length
8.76 m
Unloading rate
141 L/sec
Rated power
380 hp
Case IH 7230 Combines Listings
Compare Case IH 7230 Combine to other combines
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH 7230?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Case IH 7230?
Listed features include a longitudinal rotor separator, 11,100 L (2,932.3 US gal) grain tank, 141 L/s (2,234.9 gpm) unloading rate, and wheel propulsion. It has a Diesel engine with 328.1 kW (440 hp) engine power.
What type of engine does the 7230 use?
The 7230 uses a Diesel engine with 531 cu in displacement. Its emission standard level is Tier 4A (Interim).
How much horsepower does the 7230 have?
The 7230 has 328.1 kW (440 hp) engine power. Rated power is 283.4 kW (380 hp).
What fuel does the Case IH 7230 use?
The Case IH 7230 uses Diesel fuel. Its fuel tank capacity is 1,000 L (264.2 US gal).
What jobs is this Combines best suited for?
The supplied data identifies this machine as a combine. Its longitudinal rotor separator, 11,100 L (2,932.3 US gal) grain tank, and 141 L/s (2,234.9 gpm) unloading rate support grain-harvesting work.
What is the expected lifespan of the 7230?
The supplied data does not confirm an expected lifespan. For a used machine, inspect maintenance records, engine condition, rotor and threshing components, unloading system, fuel system, and overall wear.
What should a buyer check when purchasing a used Combines?
Check maintenance records, engine operation, fuel system, rotor and threshing components, sieve area, unloading auger and unloading system, grain tank condition, wheel condition, and signs of structural wear or leaks. Confirm that controls and safety systems operate properly.
