2015 John Deere 770G - Used, 3,044 Hours for Sale

255 hp

Minnesota, United States

Item price

$170,960

2015 John Deere 770G - Used, 3,044 Hours for Sale

Used

ID:VTK9UBGU
Minnesota, United States
Shipping to 150+ countries

Instant Rate Calculation

Usage

3,044 hr

Power

255 hp

Year

2015

Item price

$170,960

Verified Sellers Only

All sellers are screened for legitimacy via Sumsub

Pre-Sale Inspection

Request an independent inspection before you buy.

Purchase Protection

Transactions protected for both buyers and sellers.

Full-Service Shipping

Worldwide heavy equipment shipping by trusted logistics experts.

Not ready to create an account?

You can still contact us and request shipping rates.

New to JumboBee?

Watch a short guide to learn how to browse equipment, check shipping costs, and buy with confidence.

Verified Sellers

Instant Shipping Rates

Guarantees Every Transaction

Pre-sale inspections

Item description

MOTOR GRADER - HEATED COMFORT SEAT - A/C SYSTEM W/HEATING - 110V ENGINE BLOCK HEATER - ADDITIONAL FRONT HYDRAULICS - Michelin 14.00/24R snow plus tires - Rotary ejector pre-cleaner - Ether aid - Block heater - Heated premium seat - 14 foot moldboard - AM/FM/WB radio - Non-auto shift transmission - Front and rear fenders - Hydraulic pump disconnect - Rear window defrost - Front lower wipers - Non-impact blade system.

Specifications

Engine Power

255 hp

(190.2 kW)

Operating Weight

19,396 kg

Moldboard Width

12 ft

(3.7 m)

Engine hours

3,044 hr

Dimensions L×W×H

350 × 98 × 125.2 in

(8,890 × 2,490 × 3,180 mm)
Width

98 in

(2,490 mm)
Length

350 in

(8,890 mm)
Height

125.2 in

(3,180 mm)
Fuel tank

416 L

(109.9 ga)
Battery Voltage

24

Net Power (ISO 9249)

255 hp

(190.2 kW)
Displacement

549,215.8 cu(in)

(< 0.1 L)
Manufacturer and Model

PowerTech PSS 9.0L

Number of Cylinders

6

Net Peak Torque

1,318 Nm

(972.1 ft-lb)
Hydraulic System

60 L

(15.9 ga)
Powertrain Type

John Deere 8-speed (8F/8R)

Gears Forward

8

Gears Reverse

8

Maximum Travel Speed - High

45 km/h

Steering (Turning Radius)

< 0.1 ft

(< 0.1 m)
Front Axle Oscillation (total)

32 deg

Steering (Articulation)

22 deg

Maximum System Pressure

18,961 kPa

(2,750.1 psi)
Front Axle Wheel Lean Angle (each direction)

20 deg

Maximum Pump Flow

212 L/min

(56 gpm)
Blade Range - Lift Above Ground

490 mm

(19.3 in)
Blade Range - Blade Side Shift (right or left)

683 mm

(26.9 in)
Bank Cut Angle (right or left)

90 deg

(< 0.1 deg)
Pitch at Ground Line - Forward

42 deg

(< 0.1 deg)
Pitch at Ground Line - Back

5 deg

(< 0.1 deg)
Shoulder Reach Outside Wheels (frame straight, right or left)

2,083 mm

(82 in)
Blade Pull At Maximum Operating Weight

15,501 kg

(34,173.9 lb)
Blade Base

8.4 ft

(2.6 m)
Wheelbase

20.2 ft

(6.2 m)
Overall length w/header

29.2 ft

(8.9 m)
Height to top of cab

3,180 mm

Base Length

8.4 ft

(2.6 m)
Height (measured along arc, including cutting edge)

610 mm

(24 in)
Moldboard Thickness

22 mm

(0.9 in)
Operating Weight - Rear

12,084 kg

(26,640.7 lb)
Operating Weights - Total

19,396 kg

(42,760.9 lb)
Operating Weight - Front

4,305 kg

(9,490.9 lb)
Circle Diameter

1,524 mm

(60 in)
Circle Rotation

360 deg

(< 0.1 deg)
Circle Side Shift (right)

683 mm

(26.9 in)
Operators Station

Cab w/ AC
