New Holland ML12T Wheel Loaders
New Holland ML12T
5+
sold in last yearGeneral overview
New Holland ML12T is a wheel loader designed for compact loading and material-handling work in construction settings. It is powered by an 18 kW (25 hp) engine with 3 cylinders and has an operating weight of 1,200 kg (2,650 lb), placing it in a light-duty class suited to maneuverable site work.
Its compact frame and loader geometry support work in confined areas, with a width of 920 mm (3 ft), height to top of cab of 2,060 mm (6 ft 9 in), and turning radius - over bucket of 2,235 mm (7 ft 4 in). The machine also lists a travel speed forward of 15 km/h (9.3 mph) and a system relief pressure of 151.7 bar (2,200 psi), indicating a small wheel loader built for short-distance movement and controlled loading cycles.
Year
2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
2,927 mm
~115.2 in
2,060 mm
~81.1 in
920 mm
~36.2 in
Engine Power
25 hp
Operating Weight
1,200 kg
Bucket Capacity
0.4 cu(m)
Additional specifications
Displacement
cu(m)
Fuel tank
45 L
Height to top of cab
2,060 mm
Wheelbase
1,247 mm
Number of Cylinders
3
Width
920 mm
System Relief Pressure
15,168 kPa
Travel Speed Forward
15 km/h
Power - Net
25 hp
Overall Length - With Bucket
2,927 mm
Reach at Maximum Dump Height
2,820 mm
Hinge Pin at Maximum Height
2,820 mm
Turning Radius - Over Bucket
2,235 mm
Rated Operating Capacity
1,100 kg
New Holland ML12T Wheel Loaders Listings
Looking for New Holland ML12T Wheel Loaders?
See similar listingsCompare New Holland ML12T Wheel Loader to other wheel loaders
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a New Holland ML12T?
No confirmed market price is supplied for the New Holland ML12T. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the New Holland ML12T?
The supplied specifications show a compact 920 mm width, 1,200 kg operating weight, 18.6 kW (25 hp) engine power, and a 2,235 mm turning radius over the bucket. These dimensions may be useful where maneuverability and limited access matter.
What type of engine does the ML12T use?
The supplied data confirms that the ML12T has a 3-cylinder engine rated at 18.6 kW (25 hp). It does not confirm the engine manufacturer, fuel type, or engine model.
How much horsepower does the ML12T have?
The ML12T has 18.6 kW (25 hp) of engine power. Its listed net power is also 18.6 kW (25 hp).
What fuel does the New Holland ML12T use?
The supplied specifications do not confirm the fuel type for the New Holland ML12T. They list a fuel tank capacity of 45 L (11.9 US gal).
What jobs is this Wheel Loaders best suited for?
The supplied data does not specify intended applications. Its 920 mm width, 1,200 kg operating weight, and 2,235 mm turning radius over the bucket indicate a compact wheel loader configuration that may suit work in restricted-access areas.
What is the expected lifespan of the ML12T?
The supplied data does not provide an expected service-life estimate for the ML12T. Service life depends on maintenance, operating conditions, workload, and inspection history.
What should a buyer check when purchasing a used Wheel Loaders?
Check service records, operating hours, fluid leaks, engine condition, steering, brakes, tires, hydraulics, bucket and linkage wear, and safety equipment. Test the loader through its operating functions and inspect the frame and cab for damage or repairs.
