New Holland L320 Skid Steer / CTL
New Holland L320
Average price
$29,990
5+
sold in last year
General overview
The New Holland L320 is a skid steer loader manufactured in the United States and produced from 2023 to 2025. It is intended for construction work and material handling on job sites. With an operating weight of 2,930 kg (6,460 lb) and 49 kW (67 hp) of engine power, it is configured for general site work.
Power comes from the ISM / N4LDI-TA-50SL engine with Tier 4 Final emissions compliance and 47 kW (64 hp) of net power. The L320 uses an electro-hydraulic drive with single-reduction chain final drive, a max. speed of 18 km/h (11.2 mph), and a rated operating capacity of 905 kg (2,000 lb). It also provides a dump height of 2,330 mm (7 ft 8 in).
Year
2023, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Height
Width
Length
1,998 mm
~78.7 in
1,755 mm
~69.1 in
3,338 mm
~131.4 in
Engine Power
67 hp
Operating Weight
2,930 kg
Rated Operating Capacity
905 kg
Dump Height
2,330 mm
Max. speed
18 km/h
Additional specifications
Emission standard level
Tier 4 Final
Displacement
2 cu(m)
Speeds
Low range 12.5 km/h; High range 18.3 km/h (dual-range / 2-speed)
Fuel tank
73 L
Wheelbase
1,128 mm
Axles
N/A - single-reduction chain final drive (no conventional axles)
Final drive
Single-reduction chain drive
Net Power (ISO 9249)
64 hp
Manufacturer and Model
ISM / N4LDI-TA-50SL
Pump flow loader
78 L/min
2 Speed High
18 km/h
Brakes
Spring-applied, hydraulic-release disc parking brake
System Pressure at Couplers
21,000 kPa
Length Without Bucket
2,697 mm
Length With Foundry Bucket
3,338 mm
Width Without Bucket
1,755 mm
Height to Top of ROPS
1,998 mm
Height to Hinge Pin
3,073 mm
Dump Height With Foundry Bucket
2,405 mm
Dump Reach With Foundry Bucket
758 mm
Ground Clearance
203 mm
Angle of Departure
25 deg
Front Turn Radius With Foundry Bucket
2,055 mm
Dump Angle (full lift height)
52 deg
Bucket Rollback (ground level)
34 deg
Tipping Load
1,814 kg
SAE Rated Operating Capacity With Counterweight
905 kg
Boom Breakout Force With Foundry Bucket
15 kg
Boom Breakout Force With Construction Bucket
15 kg
Bucket Breakout Force With Foundry Bucket
32 kg
Bucket Breakout Force With Construction Bucket
32 kg
Powertrain Type
Electro-hydraulic drive; single-reduction chain final drive
Operating Weight - Rear
2,930 kg
Seed spacing
12 mm
New Holland L320 Skid Steer / CTL Listings
$29,400
67 hp
905 kg
2330 mm
1880 hours
Cuba City, United States
Compare New Holland L320 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a New Holland L320?
No confirmed market price is supplied for the New Holland L320. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the New Holland L320?
Listed strengths include 50 kW (67 hp) engine power, 905 kg (1,995 lb) rated operating capacity, electro-hydraulic drive, dual-range travel speeds, and 78 L/min (20.6 gpm) loader pump flow. It also has a 73 L (19.3 US gal) fuel tank and Tier 4 Final emissions level.
What type of engine does the L320 use?
The L320 is listed with an ISM / N4LDI-TA-50SL engine. The supplied specifications do not confirm a further engine type or fuel type.
How much horsepower does the L320 have?
The L320 is listed at 50 kW (67 hp) engine power. Net Power (ISO 9249) is 47.7 kW (64 hp).
What fuel does the New Holland L320 use?
The supplied specifications do not confirm the fuel type for the New Holland L320.
What jobs is this Skid Steer Loaders best suited for?
The supplied data does not specify intended jobs. For application matching, assess the 905 kg (1,995 lb) rated operating capacity, 2,330 mm (91.7 in) dump height, hydraulic flow, attachment requirements, and site access needs.
What is the expected lifespan of the L320?
The supplied data does not provide an expected lifespan for the L320. Service life depends on operating conditions, maintenance records, hydraulic and drivetrain condition, and the quality of prior repairs.
What should a buyer check when purchasing a used Skid Steer Loaders?
Inspect service records, engine starting and operation, hydraulic leaks and coupler performance, loader arms and bucket attachment points, chains and final drive, parking brake, tires, ROPS condition, and controls. Test all functions under load and verify the machine’s configuration matches the listing.
