Case IH MAGNUM 380 Row Crop Tractors
Case IH MAGNUM 380
5+
sold in last yearGeneral overview
The Case IH MAGNUM 380 is a wheeled tractor designed for large-scale field work and other heavy agricultural tasks. Produced in the United States for the 2021 model year, it uses an 8 L diesel engine rated at 279 kW (380 hp). The model is also listed as guidance ready, indicating provision for guidance-equipped operation.
The MAGNUM 380 is equipped with a CVXDrive transmission, a rear independent PTO with 540, 1000 speeds, and a Category 3/4N rear 3-point hitch. Its hydraulic system uses pressure flow compensating (PFC) with a pump rated output of 166 L/min (43.9 gpm), four rear selective control valves, and electro-hydraulic SCV control. Maximum lift capacity behind lift points is 9,026 kg (19,900 lb), and rated PTO power is 232 kW (315 hp).
Year
2021
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
6,500 mm
~255.9 in
3,370 mm
~132.7 in
3,050 mm
~120.1 in
14,605 kg
~32,198.5 lb
Tire or Track Type
wheels
Engine Power
380 hp
Additional specifications
Engine type
diesel
Displacement
8 cu(m)
Maximum PTO power
315 hp
Rated PTO power
315 hp
Transmission type
CVXDrive
Maximum lift capacity behind lift points
9,026 kg
Fuel tank
617 L
Hydraulic system type
pressure flow compensating (PFC)
Pump rated output
166 L/min
Number of rear selective control valves
4
SCV control
electro-hydraulic
Sensing type
electronic lower link draft sensing
Rear PTO
independent
Rear 3-Point Hitch
Category 3/4N
Guidance Ready
guidance_ready
Tire type
ag
PTO speed
540, 1,000
Tire Size
420/85R34 front, 480/80R50 rear
Case IH MAGNUM 380 Row Crop Tractors Listings
Looking for Case IH MAGNUM 380 Row Crop Tractors?
See similar listingsCompare Case IH MAGNUM 380 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Case IH MAGNUM 380 Row Crop Tractor
wheels
14605 kg
6500 mm × 3050 mm × 3370 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH MAGNUM 380?
No confirmed market price is supplied for the Case IH MAGNUM 380. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Case IH MAGNUM 380?
Listed features include 283.4 kW (380 hp) engine power, CVXDrive transmission, independent rear PTO, electronic lower link draft sensing, and a pressure flow compensating (PFC) hydraulic system. It also has 4 electro-hydraulic rear selective control valves and is guidance ready.
What type of engine does the MAGNUM 380 use?
The MAGNUM 380 uses a diesel engine.
How much horsepower does the MAGNUM 380 have?
The MAGNUM 380 has 283.4 kW (380 hp) of engine power. Rated and maximum PTO power are 234.9 kW (315 hp).
What fuel does the Case IH MAGNUM 380 use?
The Case IH MAGNUM 380 uses diesel fuel. Its fuel tank capacity is 617 L (163 US gal).
What jobs is this Tractors best suited for?
The supplied specifications support use with PTO-driven and hydraulic implements. Relevant features include an independent rear PTO, 4 rear selective control valves, rear 3-Point Hitch Category 3/4N, and 9,026 kg (19,899 lb) maximum lift capacity behind lift points.
What is the expected lifespan of the MAGNUM 380?
The supplied data does not confirm an expected service life for the MAGNUM 380. Evaluate maintenance records, operating history, engine condition, transmission operation, hydraulics, PTO, hitch, and tire condition.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, engine condition, CVXDrive operation, hydraulic performance, rear PTO engagement, hitch operation, SCVs, tires, fuel-system condition, and guidance equipment. Confirm that the tractor’s configuration and attachments match the intended work.
