Case IH MAGNUM 305 Row Crop Tractors
Case IH MAGNUM 305
Average price
$99,500
5+
sold in last year
General overview
Case IH MAGNUM 305 is a wheeled tractor produced in the United States for field operations and other farm work. It is powered by a 6.6 L (403 cu in) diesel engine rated at 224 kW (305 hp) and is listed with Tier 2 emissions.
The model uses a Partial power shift 16×4 transmission, a Closed-center PFC hydraulic system, and a hydraulic pump rated at 132 L/min (34.9 gpm). It has 3 rear selective control valves, Rear hitch Category III, and a maximum lift capacity behind lift points of 8,845 kg (19,500 lb). PTO output is rated at 194 kW (264 hp) and reaches 207 kW (281 hp), with a base machine weight of 11,064 kg (24,390 lb) for mounted and PTO-driven implements.
Year
1997, 1998, 1999, 2000, 2001, 2002, 2003, 2008
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,540 mm
~100 in
3,080 mm
~121.3 in
5,760 mm
~226.8 in
11,064 kg
~24,392 lb
Tire or Track Type
Wheels
Engine Power
305 hp
Additional specifications
Emission standard level
Tier 2
Engine type
Diesel
Displacement
403 cu(in)
Tires front
480/80R46
Maximum PTO power
281 hp
Rated PTO power
264 hp
Speeds
540/1,000 rpm
Transmission type
Partial power shift 16×4
Rear hitch category (SAE designation)
Category III
Base machine weight
11,064 kg
Maximum lift capacity behind lift points
8,845 kg
Fuel tank
825 L
Cab glass area
Hydraulic system type
Closed-center PFC
Pump rated output
132 L/min
Available flow at a single rear SCV
132 L/min
Number of rear selective control valves
3
SCV control
Mechanical lever
Sensing type
Draft control
Tires rear
580/80R42
Case IH MAGNUM 305 Row Crop Tractors Listings
Compare Case IH MAGNUM 305 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Case IH MAGNUM 305 Row Crop Tractor
305 hp
11064 kg
5760 mm × 2540 mm × 3080 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH MAGNUM 305?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, configuration, service history, and included equipment.
What are the key advantages of the Case IH MAGNUM 305?
Key listed capabilities include 227.4 kW (305 hp) engine power, closed-center PFC hydraulics, 132 L/min (34.9 gpm) pump output, three rear SCVs, and 8,845 kg (19,500 lb) maximum lift capacity behind the lift points.
What type of engine does the MAGNUM 305 use?
The MAGNUM 305 uses a diesel engine with 403 cu in displacement and a Tier 2 emission standard level.
How much horsepower does the MAGNUM 305 have?
The MAGNUM 305 has 227.4 kW (305 hp) of engine power. Rated PTO power is 196.9 kW (264 hp), and maximum PTO power is 209.5 kW (281 hp).
What fuel does the Case IH MAGNUM 305 use?
The Case IH MAGNUM 305 uses diesel fuel. Its listed fuel tank capacity is 825 L (217.9 US gal).
What jobs is this Tractors best suited for?
Its listed power, PTO output, hydraulic flow, rear hitch, and lift capacity indicate suitability for demanding PTO- and hydraulically driven farm implements. The supplied data does not identify specific recommended jobs or implements.
What is the expected lifespan of the MAGNUM 305?
The supplied data does not provide an expected service life. Actual lifespan depends on maintenance, operating conditions, workload, repair history, and the condition of the engine, transmission, hydraulics, and hitch.
What should a buyer check when purchasing a used Tractors?
Check service records and inspect engine operation, transmission shifting, hydraulic functions, rear SCVs, PTO operation, hitch lift, tires, fuel system, and signs of leaks or structural damage. Verify that the controls and draft-control system operate correctly.
