Case IH MAGNUM 245 Row Crop Tractors
Case IH MAGNUM 245
Average price
$106,500
5+
sold in last year
General overview
Case IH MAGNUM 245 is a wheeled farm tractor used for agricultural field operations. Produced in the United States, it is powered by an 8 L diesel engine rated at 182 kW (248 hp). The model is built for work with mounted and towed implements rather than light-duty chores.
An 18-speed full powershift transmission supports operation across changing field conditions, while the independent rear PTO and Category III/IIIN rear 3-point hitch provide implement compatibility. Its closed-center/high-capacity hydraulic system delivers 166 L/min (43.9 gpm), and the rear hitch lift capacity is 6,382 kg (14,070 lb). A suspended front axle and six rear selective control valves further support implement handling.
Year
2008, 2009, 2010, 2011
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Weight
mm
~ in
3,048 mm
~120 in
12,020 kg
~26,499.6 lb
Tire or Track Type
wheels
Engine Power
248 hp
Additional specifications
Engine type
diesel
Displacement
8 cu(m)
Maximum PTO power
242 hp
Rated PTO power
200 hp
Transmission type
18-speed full powershift
Maximum lift capacity behind lift points
6,382 kg
Fuel tank
681 L
Hydraulic system type
closed-center/high-capacity hydraulic system
Pump rated output
166 L/min
Available flow at a single rear SCV
166 L/min
Number of rear selective control valves
6
Hitch type
3
Rear PTO
Independent rear PTO
Front Axle
Suspended front axle
Rear 3-Point Hitch
Category III/IIIN
Additional Options
Deluxe cab, A/C, air suspension seat
Tire type
Radial agricultural tires
PTO speed
["1,000", "540", "1,000"]
Tire Size
Front 380/85R34, Rear 480/80R46
Case IH MAGNUM 245 Row Crop Tractors Listings
Compare Case IH MAGNUM 245 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH MAGNUM 245?
No confirmed market price is supplied. Check current listings and compare the tractor’s condition, location, and configuration.
What are the key advantages of the Case IH MAGNUM 245?
Listed features include an 18-speed full powershift transmission, suspended front axle, independent rear PTO, closed-center/high-capacity hydraulic system, up to 6 rear selective control valves, and available Deluxe cab, A/C, and air suspension seat.
What type of engine does the MAGNUM 245 use?
The MAGNUM 245 uses a diesel engine.
How much horsepower does the MAGNUM 245 have?
Engine power is 184.9 kW (248 hp). Rated PTO power is 149.1 kW (200 hp), with maximum PTO power of 180.5 kW (242 hp).
What fuel does the Case IH MAGNUM 245 use?
The Case IH MAGNUM 245 uses diesel fuel.
What jobs is this Tractors best suited for?
The supplied specifications do not confirm specific intended jobs. Its listed PTO, rear hitch, hydraulic system, and rear selective control valves indicate compatibility with implements that match its available connections and capacities.
What is the expected lifespan of the MAGNUM 245?
No expected service-life figure is supplied. For a used tractor, inspect maintenance records, engine condition, transmission operation, hydraulic performance, PTO function, hitch operation, tires, and signs of leaks or wear.
What should a buyer check when purchasing a used Tractors?
Check maintenance records, diesel-engine condition, operation of the 18-speed full powershift transmission, hydraulic output and rear selective control valves, PTO operation, rear hitch lift function, front-axle suspension, tire condition, cab equipment, and leaks or visible damage.
