Case IH MAGNUM 180 Row Crop Tractors
Case IH MAGNUM 180
5+
sold in last yearGeneral overview
Case IH MAGNUM 180 is a wheeled farm tractor built in the United States for field work and other drawbar or PTO-driven tasks. The Case IH MAGNUM 180 uses a 6 L diesel engine rated at 132 kW (180 hp) and meets Stage 3B emission standards. It was produced for the 2009 and 2010 model years.
Power delivery is available through an 18F/6R full powershift (PowerDrive) or CVXDrive CVT transmission, paired with a 4WD front steer axle and planetary final drives. The tractor has an independent rear PTO with 540 and 1000 speeds, rated PTO power of 110 kW (150 hp), maximum PTO power of 132 kW (180 hp), and a rear 3-point hitch in Category II / 3N / III (adjustable) with a maximum lift capacity behind lift points of 5,800 kg (12,790 lb).
Year
2009, 2010
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
Weight
5,944 mm
~234 in
3,265 mm
~128.5 in
3,020 mm
~118.9 in
8,618 kg
~18,999.5 lb
Tire or Track Type
wheels
Engine Power
180 hp
Additional specifications
Emission standard level
Stage 3B
Engine type
diesel
Displacement
6 cu(m)
Maximum PTO power
180 hp
Rated PTO power
150 hp
Transmission type
18F/6R full powershift (PowerDrive) or CVXDrive CVT
Maximum lift capacity behind lift points
5,800 kg
Fuel tank
446 L
Hydraulic system type
Pressure Flow Compensated (PFC), closed-center
Pump rated output
150 L/min
Number of rear selective control valves
3
Sensing type
Electronic, lower-link
Hitch type
2
Rear PTO
independent
Front Axle
4WD front steer, planetary final drives
Rear 3-Point Hitch
Category II / 3N / III (adjustable)
Tire width
380 mm
Additional Options
CVT vs powershift, high-capacity 3-pt, 3–5 rear SCVs, tire/dual configurations, DEF Tier 4A emissions
Tire type
380/85 R34 front, 480/80 R46 rear duals
PTO speed
["540", "1,000"]
Tire Size
380/85 R34; 480/80 R46
Case IH MAGNUM 180 Row Crop Tractors Listings
Looking for Case IH MAGNUM 180 Row Crop Tractors?
See similar listingsCompare Case IH MAGNUM 180 Row Crop Tractor to other row crop tractors
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Case IH MAGNUM 180 Row Crop Tractor
wheels
8618 kg
5944 mm × 3020 mm × 3265 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH MAGNUM 180?
No confirmed market price is supplied for the Case IH MAGNUM 180. Check current listings and compare condition, location, hours, maintenance history, and configuration.
What are the key advantages of the Case IH MAGNUM 180?
Listed features include 134.2 kW (180 hp) engine power, independent rear PTO with 540 and 1000 speeds, 4WD front steer, a PFC closed-center hydraulic system, and an adjustable rear three-point hitch.
What type of engine does the MAGNUM 180 use?
The MAGNUM 180 uses a diesel engine with a Stage 3B emission standard level.
How much horsepower does the MAGNUM 180 have?
The Case IH MAGNUM 180 has 134.2 kW (180 hp) of engine power.
What fuel does the Case IH MAGNUM 180 use?
The Case IH MAGNUM 180 uses diesel fuel.
What jobs is this Tractors best suited for?
The supplied specifications do not identify specific intended jobs. Its 4WD front steer, rear three-point hitch, rear PTO, and hydraulic system support use with compatible mounted, PTO-driven, and hydraulic implements.
What is the expected lifespan of the MAGNUM 180?
The supplied data does not provide an expected service-life estimate. Actual lifespan depends on operating conditions, maintenance history, service quality, and inspection of major systems.
What should a buyer check when purchasing a used Tractors?
Inspect the engine, transmission, 4WD front axle, PTO operation, rear hitch, hydraulics, selective control valves, tires, and fuel system. Review maintenance records and confirm the installed transmission, PTO, hydraulic, and tire configuration.
