Case IH 330 Vertical Tillage
Case IH 330
5+
sold in last yearGeneral overview
The Case IH 330 is a vertical tillage attachment designed for field preparation in crop production. Built in the United States, it is used to size and mix residue and help level soil before planting. The model has a working width of 6,760 mm (22 ft 2 in) and requires 202 kW (275 hp), placing it in a higher-power class for broad-acre tillage work. Its size and power requirement suit large field passes where consistent coverage is important.
Depth control is handled through mechanical gang angle adjustment, with hydraulically adjustable gang angles and optional in-cab control. These features let the Case IH 330 adapt its working angle to changing field conditions while operating at 12 km/h (7.5 mph). The specification set emphasizes residue management, soil leveling, and controlled field coverage across repeated passes.
Year
2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020
Country of manufacturing
United States
General specifications
Dimensions
Height
Width
3,454 mm
~136 in
5,639 mm
~222 in
Working Width
6,760 mm
Additional specifications
Working speed
12 km/h
Residue Conditions
Efficiently sizes and mixes residue; levels soil for uniform seed bed preparation
Depth control
Mechanical gang angle adjustment available; hydraulically adjustable gang angles with optional in-cab control
Required HP (PTO)
275 hp
Case IH 330 Vertical Tillage Listings
Looking for Case IH 330 Vertical Tillage?
See similar listingsCompare Case IH 330 Vertical Tillage to other vertical tillage
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Case IH 330?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Case IH 330?
Key stated benefits include efficient residue sizing and mixing, soil leveling for uniform seed bed preparation, and adjustable gang angles. Mechanical gang angle adjustment is available, with hydraulically adjustable gang angles and optional in-cab control.
What type of engine does the 330 use?
The supplied information does not confirm an engine type for the Case IH 330.
How much horsepower does the 330 have?
The Case IH 330 requires 205.1 kW (275 hp) PTO power. This is a required power specification, not an engine output rating.
What fuel does the Case IH 330 use?
The supplied information does not confirm the fuel type for the Case IH 330.
What jobs is this Vertical Tillage best suited for?
It is suited for sizing and mixing crop residue, leveling soil, and preparing a uniform seed bed. The stated working width is 6,760 mm (266.1 in), and the listed working speed is 12 km/h (7.5 mph).
What is the expected lifespan of the 330?
The supplied information does not provide an expected lifespan. Service life depends on operating conditions, maintenance, storage, and the condition of wear components.
What should a buyer check when purchasing a used Vertical Tillage?
Inspect the frame, gangs, adjustment mechanisms, hydraulic components, and wear parts for damage, excessive wear, or leaks. Verify gang-angle adjustment operation, check for uneven working components, and confirm compatibility with the tractor's available PTO power.
