2023 John Deere 772G - Used, 2,997 Hours for Sale

275 hp

Wyoming, United States

Item price

$282,500

2023 John Deere 772G - Used, 2,997 Hours for Sale

Used

ID:RHCE37SV
Wyoming, United States
Shipping to 150+ countries

Instant Rate Calculation

Usage

2,997 hr

Power

275 hp

Year

2023

Item price

$282,500

Verified Sellers Only

All sellers are screened for legitimacy via Sumsub

Pre-Sale Inspection

Request an independent inspection before you buy.

Purchase Protection

Transactions protected for both buyers and sellers.

Full-Service Shipping

Worldwide heavy equipment shipping by trusted logistics experts.

Not ready to create an account?

You can still contact us and request shipping rates.

New to JumboBee?

Watch a short guide to learn how to browse equipment, check shipping costs, and buy with confidence.

Verified Sellers

Instant Shipping Rates

Guarantees Every Transaction

Pre-sale inspections

Item description

MOTOR GRADER - CAB/AC/HEAT - AIR SEAT - CLOTH SEAT - FWD - 14' BLD - RIPP - FRT HYD - CIRCLE SLIP CLUTCH - RADIO

Specifications

Engine Power

275 hp

(205.1 kW)

Operating Weight

17,502 kg

Moldboard Width

12 ft

(3.7 m)

Engine hours

2,997 hr

Dimensions L×W×H

350 × 98 × 125.2 in

(8,890 × 2,490 × 3,180 mm)
Width

98 in

(2,490 mm)
Length

350 in

(8,890 mm)
Height

125.2 in

(3,180 mm)
Displacement

549,215.8 cu(in)

(< 0.1 L)
Manufacturer and Model

John Deere PowerTech PSS 9.0L

Net Power (ISO 9249)

275 hp

(205.1 kW)
Number of Cylinders

6

Fuel tank

416 L

(109.9 ga)
Cooling system

45 L

(11.9 ga)
Hydraulic System

60 L

(15.9 ga)
Engine Oil

29 L

(7.7 ga)
Battery Voltage

24

Alternator Rating

55

Overall width

98 in

(2.5 m)
Net Peak Torque

1,375 Nm

(1,014.1 ft-lb)
Main Pump Type

Closed center variable displacement

Powertrain Type

John Deere powershift (8F/8R)

Front Axle Oscillation (total)

32 deg

Front Axle Wheel Lean Angle (each direction)

20 deg

Steering (Articulation)

22 deg

Steering (Turning Radius)

< 0.1 ft

(< 0.1 m)
Gears Forward

8

Gears Reverse

8

Maximum Travel Speed - High

45 km/h

Maximum System Pressure

18,961 kPa

(2,750.1 psi)
Maximum Pump Flow

212 L/min

(56 gpm)
Blade Range - Lift Above Ground

490 mm

(19.3 in)
Blade Range - Blade Side Shift (right or left)

683 mm

(26.9 in)
Pitch at Ground Line - Forward

42 deg

(< 0.1 deg)
Pitch at Ground Line - Back

5 deg

(< 0.1 deg)
Shoulder Reach Outside Wheels (frame straight, right or left)

2,083 mm

(82 in)
Bank Cut Angle (right or left)

90 deg

(< 0.1 deg)
Blade Pull At Maximum Operating Weight

22,453 kg

(49,500.4 lb)
Blade Base

8.4 ft

(2.6 m)
Height to top of cab

3,180 mm

Wheelbase

20.2 ft

(6.2 m)
Overall length w/header

29.2 ft

(8.9 m)
Moldboard Thickness

22 mm

(0.9 in)
Height (measured along arc, including cutting edge)

610 mm

(24 in)
Base Length

12 ft

(3.7 m)
Cutting Edge - Thickness

16 mm

(0.6 in)
Cutting Edge - Width

152 mm

(6 in)
Ground Clearance (front axle)

587 mm

(23.1 in)
Circle Diameter

1,524 mm

(60 in)
Circle Rotation

360 deg

(< 0.1 deg)
Circle Side Shift (right)

683 mm

(26.9 in)
Operating Weights - Total

17,502 kg

(38,585.3 lb)
Operating Weight - Front

4,881 kg

(10,760.8 lb)
Operating Weight - Rear

12,501 kg

(27,560 lb)
Operators Station

Cab w/ AC

Attachments

Ripper
