2023 Case TR340B - Used for Sale

90 hp

Illinois, United States

Item price

$32,500

2023 Case TR340B - Used for Sale

Used

ID:A6UP926X
Illinois, United States
Shipping to 150+ countries

Instant Rate Calculation

Power

90 hp

Year

2023

Item price

$32,500

Verified Sellers Only

All sellers are screened for legitimacy via Sumsub

Pre-Sale Inspection

Request an independent inspection before you buy.

Purchase Protection

Transactions protected for both buyers and sellers.

Full-Service Shipping

Worldwide heavy equipment shipping by trusted logistics experts.

Not ready to create an account?

You can still contact us and request shipping rates.

New to JumboBee?

Watch a short guide to learn how to browse equipment, check shipping costs, and buy with confidence.

Verified Sellers

Instant Shipping Rates

Guarantees Every Transaction

Pre-sale inspections

Item description

UNIT IS IN STOCK READY TO GO! FRESHLY SERVICED! HI FLOW PLUS PACKAGE 2 SPEED EH CONTROLS LCD DISPLAY W/BACKUP QUICK COUPLER HEAVY COUNTERWEIGHT HVAC CAB BLOCK HEATER SELF LEVEL FRONT ELECTRIC MULTIFUNCTION AIR RIDE SUSPENSION SEAT RIDE CONTROL

Specifications

Operating Weight

4,536 kg

Rated Operating Capacity

1,542 kg

Operating weight

9,656.3 lb

(4,380 kg)

Dimensions L×W×H

118.1 × 76.4 × 80.3 in

(3,000 × 1,940 × 2,040 mm)
Width

76.4 in

(1,940 mm)
Length

118.1 in

(3,000 mm)
Height

80.3 in

(2,040 mm)
Operating weight

9,656.3 lb

(4,380 kg)
Engine Power

90 hp

Displacement

3,400 cu(cm)

Manufacturer and Model

FPT F5B FL413 D*C001

Emission standard level

Tier 4 Final

Speeds

Two ranges: low 8.2 km/h; high 12.9 km/h

Fuel tank

96.5 L

Fuel Type

Diesel

Final drive

Planetary gearbox with two-speed motor

Ground Pressure

30.3 kPa

Tractive Effort

32.98 kN

Brakes

Spring-applied, hydraulically released multiple-disc parking brake

Single

8.2 km/h

2 Speed High

12.9 km/h

Two-Speed

Yes

Length Without Bucket

3,000 mm

Length With Foundry Bucket

3,620 mm

Width Without Bucket

1,940 mm

Height to Top of ROPS

2,040 mm

Height to Hinge Pin

3,220 mm

Dump Height With Foundry Bucket

2,590 mm

Dump Reach With Construction Bucket

630 mm

Ground Clearance

240 mm

Angle of Departure

32°

Front Turn Radius With Foundry Bucket

2,190 mm

Dump Angle (full lift height)

38.1°

Bucket Rollback (ground level)

30.6°

Tipping Load

3,084 kg

SAE Rated Operating Capacity With Counterweight

1,633 kg

Rated operating capacity standard

1079 kg at 35% tipping load; 1542 kg at 50%

Boom Breakout Force With Construction Bucket

3,519.94 kg

Bucket Breakout Force With Construction Bucket

3,946.25 kg

Dump Height

2,590 mm

Bucket volume

0.5 cu(m)

Max. speed

12.9 km/h

Powertrain Type

Diesel, two-speed hydrostatic

Cylinders

4

Pump flow standard

91.5 L/min

Product Configuration

High Flow Plus Package

Hydraulic High Flow

Yes

Self Leveling

Yes

Ride Control

Yes

ROPS

Enclosed

Operator Controls

Hand

Track Width

450 mm

Operating weight base machine

4,536 kg

Undercarriage type

Rubber tracks

Length of Track on Ground

1,640 mm

Voltage

12 V

Number of batteries 12v

1

Battery Capacity

1000 CCA at -18°C

Alternator Rating

160 A
