Westfield WRX10-41 Grain Auger
Westfield WRX10-41
5+
sold in last yearGeneral overview
Year
2024
Country of manufacturing
Canada
General specifications
Dimensions
Length
Height
Width
Weight
12,598.4 mm
~496 in
3,352.8 mm
~132 in
2,390 mm
~94.1 in
449 kg
~989.9 lb
Additional specifications
Drive type
PTO
Axle
2-1/2 in x 1-1/8 in wall square tubing
Wheel Size
15 in
Capacity (bushels per hour)
Up to 4,800 bu/h
Recommended PTO Horsepower
40 hp
Tractor PTO RPM
540 rpm
HP Intake Diameter
254 mm
Flighting - Standard Intake
10 GA welded with Wear Edge Technology; lower pitch for high capacity
Flighting - Main
9 in OD x 7 GA stretched and welded
1/4" Core Diameter
50.8 mm
Top Drive Chain
#80 roller chain with hardened steel sprockets
Lower Bearing Size
31.75 mm
Gearbox Shaft Diameter
31.75 mm
Frame Arms
Upper lift arms sit back from the axle and tuck away
Hydraulic Requirements
22 GPM at 2,200 PSI
Tire Size
15 in agricultural tires
Lift Mechanism
Reduction-geared winch with automotive brake; optional hydraulic winch
Rated Capacity
Up to 4,800 BPH
Mobility Type
Trailed/towable truck auger
Recommended PTO engine power
40 hp
