Westfield MK0861 Grain Auger
Westfield MK0861
5+
sold in last yearGeneral overview
Westfield MK0861 is a grain auger from Westfield, a 2024 model manufactured in Canada, for moving grain in farm handling and storage operations. It is designed for tractor PTO operation at 540 RPM and requires 33 kW (45 hp).
The model is rated at 3,900 bu/h and uses an intake diameter of 203 mm (8 in). It has a raised height of 12,344 mm (40 ft 6 in), a transport length of 18,593 mm (61 ft), and a transport height of 4,114 mm (13 ft 6 in). Tube construction is 14 GA Welded Steel with 10 GA Stretched & Welded main flighting. A 3" x 11 GA Frame lift mechanism, one 4" cylinder with 5/16" Aicraft Cable, and 950 PSI hydraulic requirements support positioning.
Year
2024
Country of manufacturing
Canada
General specifications
Dimensions
Width
Height
Length
Weight
2,844 mm
~112 in
4,114 mm
~162 in
18,593 mm
~732 in
847 kg
~1,867.3 lb
Capacity (bushels per hour)
3,900 bu/h
Recommended PTO Horsepower
45 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
PTO
HP Intake Diameter
203 mm
Height - Raised
12,344 mm
Reach - Lowered
8,788 mm
Reach - Raised
7,086 mm
Tube Thickness
14 GA Welded Steel
Flighting - Main
10 GA Stretched & Welded
Transport Length
18,593 mm
Transport Height
4,114 mm
Wheel Track Width
2,844 mm
Undercarriage Axle
2 ½" x 2 ½" x 1/8" Wall Square Tubing
Number of Hydraulic Cylinders
One 4" Cylinder with 5/16" Aicraft Cable
Hydraulic Requirements
950 PSI
Tire Size
15" Agricultural Tires
Lift Mechanism
3" x 11 GA Frame
Westfield MK0861 Grain Auger Listings
Looking for Westfield MK0861 Grain Auger?
See similar listingsCompare Westfield MK0861 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Westfield MK0861?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Westfield MK0861?
Listed features include 3,900 bu/h capacity, a 203 mm (8 in) intake, 12,344 mm (486 in) raised height, and one 4" hydraulic cylinder with 5/16" Aicraft Cable. It also uses 15" Agricultural Tires for transport.
What type of engine does the MK0861 use?
No engine type is specified. The supplied specifications list a tractor PTO requirement of 540 RPM.
How much horsepower does the MK0861 have?
The recommended tractor PTO power is 33.6 kW (45 hp).
What fuel does the Westfield MK0861 use?
No fuel type is specified. The MK0861 is listed with a tractor PTO requirement of 540 RPM.
What jobs is this Grain Auger best suited for?
As a Grain Auger, it is suited for grain-handling work where a tractor-powered auger is appropriate. Its listed capacity is 3,900 bu/h, with a 203 mm (8 in) intake and a recommended tractor PTO power of 33.6 kW (45 hp).
What is the expected lifespan of the MK0861?
The supplied data does not confirm an expected lifespan. Service life depends on maintenance, operating conditions, storage, and inspection of the tube, flighting, hydraulic system, tires, and PTO-related components.
What should a buyer check when purchasing a used Grain Auger?
Inspect the tube and flighting for wear or damage, and check the hydraulic cylinder, cable, hoses, tires, axle, and lift mechanism. Verify that the auger raises, lowers, and operates properly with the required tractor PTO setup.
