Westfield 10X73 Grain Auger
Westfield 10X73
Average price
$21,350
5+
sold in last year
General overview
The Westfield 10X73 is a grain auger intended for farm grain handling and transfer. It is a towed model with a towbar and hitch jack, and it is specified for tractors with a 540 rpm PTO. Westfield lists a recommended PTO horsepower of 48 kW (65 hp), placing it in a tractor-matched operating range for moving grain between storage and handling points.
Key dimensions define its handling range and setup. The auger has a 254 mm (10 in) intake diameter, a reach of 5,944 mm (19 ft 6 in) lowered and 7,315 mm (24 ft) raised, and a transport length of 22,250 mm (73 ft). Other listed features include a single hydraulic cylinder lift, heavy-duty cable trussing, an extendable axle, and an operating weight of 267 kg (589 lb).
Year
2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
Canada
General specifications
Dimensions
Length
Height
Width
22,250 mm
~876 in
4,318 mm
~170 in
2,692 mm
~106 in
Tractor PTO speed
540
Capacity (bushels per hour)
18,927 L/min
Recommended PTO Horsepower
65 hp
Tractor PTO RPM
540
Additional specifications
Drive type
PTO drive
Operating Weight
267 kg
Operating width
1,219 mm
Axle
Extendable (32" on longer models); high strength 2" OD x 11 GA tubing
Wheel Size
16" x 6.70" TRF (10-ply)
Upper Bar Length
1,524 mm
HP Intake Diameter
254 mm
Reach - Lowered
5,944 mm
Reach - Raised
7,315 mm
Reach - Intake
2,057 mm
Tube Thickness
3,56 mm
Flighting - Standard Intake
Wear Edge Technologyâ„¢
Flighting - HP Intake
65 mm
Flighting - Main
6.35 mm
1/4" Core Diameter
60 mm
Top Drive Chain
Hardened tooth sprocket with HD #80 chain
Transport Length
22,250 mm
Transport Height
4,318 mm
Wheel Track Width
2,692 mm
Lower Bearing Size
60 mm
Gearbox Shaft Diameter
38 mm
Weight - Hitch
907 kg
Frame Arms
"A" frame with towbar & hitch jack; heavy-duty cable trussing
Number of Hydraulic Cylinders
1
Hydraulic Requirements
1,400 PSI required; hoses, shut-off valve, tractor-end couplers
Tire Size
15" mounted on rims; flat-free option
Tire Ply Rating
10
Height w/ Extension
1,016 mm
Number of Horizontal Flights
4
Number of Wheels
4
Lift Mechanism
Single hydraulic cylinder lift; hopper lift winch
Westfield 10X73 Grain Auger Listings
Compare Westfield 10X73 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Westfield 10X73?
No confirmed market price is supplied for the Westfield 10X73. Check current listings and compare the machine’s condition, location, and configuration.
What are the key advantages of the Westfield 10X73?
Listed features include Wear Edge Technologyâ„¢ on the standard intake, a single hydraulic cylinder lift with hopper lift winch, heavy-duty cable trussing, and a hardened tooth sprocket with HD #80 chain. It also has an extendable axle and four wheels.
What type of engine does the 10X73 use?
The supplied specifications do not identify an engine. The 10X73 is specified for tractor PTO operation at 540 rpm.
How much horsepower does the 10X73 have?
The 10X73 has a recommended PTO requirement of 48.5 kW (65 hp). The supplied data does not list engine horsepower for the auger itself.
What fuel does the Westfield 10X73 use?
No fuel type is specified. The supplied data lists tractor PTO operation at 540 rpm rather than an onboard engine.
What jobs is this Grain Auger best suited for?
As a Grain Auger, the Westfield 10X73 is suited to grain-handling work where a tractor PTO-driven auger is appropriate. The supplied specifications list a 540 rpm tractor PTO requirement and 18,927 L/min (5,000 gpm) capacity.
What is the expected lifespan of the 10X73?
The supplied data does not confirm an expected service life. Inspect the tube, flighting, bearings, drive chain, gearbox shaft, hydraulic cylinder, tires, and frame trussing, and review maintenance history before purchase.
What should a buyer check when purchasing a used Grain Auger?
Check the tube and flighting for wear or damage; inspect bearings, drive chain, sprockets, gearbox shaft, hydraulic cylinder, hoses, and couplers. Also check the frame, trussing, hitch, axle, wheels, tires, lift function, and PTO operation.
