Volvo ECR50F Compact & Mini (Tracked) Excavators
Volvo ECR50F
Average price
$52,500
5+
sold in last year
General overview
Volvo ECR50F is an excavator designed for digging, trenching, and loading work on construction sites and other earthmoving projects. It combines an operating weight of 5,050 kg (11,130 lb) with 30 kW (41 hp) from a Volvo D2.4H engine and is listed with a Stage V emission standard.
The machine uses a 4-cylinder, 2 L engine and a hydraulic system with 32 cc pumps and a maximum rated flow of 120 L/min (31.7 gpm). Travel speeds are 2 km/h (1.2 mph) low and 4 km/h (2.5 mph) high. Working dimensions include a maximum digging depth of 3,660 mm (12 ft), maximum reach at ground level of 5,910 mm (19 ft 5 in), and a maximum loading height of 4,052 mm (13 ft 4 in). Two stick lengths, 1,400 mm and 1,800 mm, are listed.
Year
2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
Sweden
General specifications
Dimensions
Length
Width
5,198 mm
~204.6 in
2,000 mm
~78.7 in
Engine Power
41 hp
Emission standard level
Stage V
Displacement
2 cu(m)
Fuel tank
70 L
Alternator output
70
Number of batteries
1
Number of Cylinders
4
Dimensions
0.15 mm
Width
2,000 mm
Operating Weight
5,050 kg
Reference Bucket Capacity
cu(m)
Maximum Rated Flow
120 L/min
Hydraulic Pumps
31.7 cu(cm)
Hydraulic Capacity
70 L
Engine Model
Volvo D2.4H
Maximum Travel Speed - Low
2 km/h
Maximum Travel Speed - High
4 km/h
Battery Capacity
74
Engine Oil
8 L
Hydraulic System - Including Tank
70 L
Track Gauge
400 mm
Maximum Digging Depth
3,660 mm
Maximum Reach at Ground Level
5,910 mm
Maximum Cutting Height
5,634 mm
Maximum Loading Height
4,052 mm
Bucket Digging Force - ISO
36 kN
Stick Digging Force - ISO
25 kN
Stick length
1,400 mm
Net Power (ISO 9249)
41 hp
Additional specifications
Rated power
27.5 kW
Header
Volvo ECR50F
Additional Options
Two stick lengths: 1,400 mm and 1,800 mm
Volvo ECR50F Compact & Mini (Tracked) Excavators Listings
$52,500
41 hp
5050 kg
Volvo D2.4H
840 hours
Holgate, United States
Compare Volvo ECR50F Compact & Mini (Tracked) Excavator to other compact & mini (tracked) excavators
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Volvo ECR50F Compact & Mini (Tracked) Excavator
41 hp
5198 mm × 2000 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Volvo ECR50F?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Volvo ECR50F?
The supplied specifications list a 30.6 kW (41 hp) Volvo D2.4H engine, Stage V emissions level, 5,050 kg (11,133 lb) operating weight, 120 L/min (31.7 gpm) maximum rated hydraulic flow, and two available stick lengths: 1,400 mm and 1,800 mm.
What type of engine does the ECR50F use?
The ECR50F uses a Volvo D2.4H engine. It is listed with 4 cylinders, 30.6 kW (41 hp), and a Stage V emission standard level.
How much horsepower does the ECR50F have?
The ECR50F has 41 hp (30.6 kW) of engine power. Net Power (ISO 9249) is also listed as 30.6 kW (41 hp).
What fuel does the Volvo ECR50F use?
The supplied data does not confirm the fuel type. It lists a 70 L (18.5 US gal) fuel tank but does not identify the fuel.
What jobs is this Excavators best suited for?
The supplied data does not identify specific job applications. Its listed operating weight is 5,050 kg (11,133 lb), with a maximum digging depth of 3,660 mm (144.1 in) and maximum reach at ground level of 5,910 mm (232.7 in).
What is the expected lifespan of the ECR50F?
The supplied data does not provide an expected service life. For a used unit, inspect maintenance records, hydraulic-system condition, engine operation, undercarriage wear, and signs of leaks or structural damage.
What should a buyer check when purchasing a used Excavators?
Check maintenance records, engine starting and operation, hydraulic response and leaks, undercarriage and track wear, bucket and attachment condition, structural damage, controls, and all available functions. Confirm the machine's configuration, including its stick length and included equipment.
