Toro TX525 Skid Steer / CTL
Toro Wheel Horse TX525
5+
sold in last yearGeneral overview
The Toro Wheel Horse TX525 is a skid steer loader used for loading and material handling on construction sites and other jobsite tasks. It is powered by a Kubota D902 diesel engine rated at 18 kW (24 hp), and the model is listed for production from 2009 to 2026 in the United States.
Key operating figures include a rated operating capacity of 250 kg (551 lb), a tipping load of 716 kg (1,580 lb), and an operating weight of 863 kg (1,900 lb). The TX525 uses a dual hydrostatic pump traction drive with stepless hydrostatic travel, plus a loader pump flow of 64 L/min (16.9 gpm) and system pressure at couplers of 206.8 bar (3,000 psi). Its published dump height is 1,170 mm (3 ft 10 in), and maximum speed is 7 km/h (4.3 mph).
Year
2009, 2010, 2011, 2012, 2013, 2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
2,336 mm
~92 in
1,170 mm
~46.1 in
1,041 mm
~41 in
Engine Power
24 hp
Operating Weight
863.6 kg
Rated Operating Capacity
250 kg
Dump Height
1,170 mm
Max. speed
7 km/h
Additional specifications
Emission standard level
4 Cycle Diesel Tier 4
Displacement
cu(m)
Speeds
Stepless hydrostatic; no 2-speed published
Fuel tank
23 L
Wheelbase
792 mm
Battery Voltage
12
Net Power (ISO 9249)
24 hp
Manufacturer and Model
Kubota D,902 diesel
Pump flow loader
64 L/min
System Pressure at Couplers
20,684 kPa
Hydraulic Horsepower Flow
24 hp
Length Without Bucket
1,795 mm
Length With Foundry Bucket
2,336 mm
Width Without Bucket
1,041 mm
Height to Top of ROPS
1,170 mm
Height to Hinge Pin
1,671 mm
Dump Height With Foundry Bucket
1,170 mm
Dump Reach With Foundry Bucket
553 mm
Ground Clearance
116 mm
Dump Angle (full lift height)
38 deg
Tipping Load
716 kg
Powertrain Type
Dual hydrostatic pump traction drive
Operating Weight - Rear
863 kg
Cylinders
3
Toro TX525 Skid Steer / CTL Listings
Looking for Toro TX525 Skid Steer / CTL?
See similar listingsCompare Toro TX525 Skid Steer / CTL to other skid steer / ctl
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Toro Wheel Horse TX525?
No confirmed market price is supplied for the Toro Wheel Horse TX525. Check current listings and compare machine condition, location, configuration, attachments, and maintenance history.
What are the key advantages of the Toro Wheel Horse TX525?
The listed advantages include a compact 1,041 mm width without bucket, a 250 kg rated operating capacity, dual hydrostatic pump traction drive, and 64 L/min loader pump flow. It also has a Kubota D902 diesel engine rated at 17.9 kW (24 hp).
What type of engine does the TX525 use?
The TX525 uses a Kubota D902 diesel engine. It is a 3-cylinder, 4 Cycle Diesel Tier 4 engine with net power rated under ISO 9249.
How much horsepower does the TX525 have?
The TX525 has 17.9 kW (24 hp) of engine power. Its Net Power (ISO 9249) is also listed as 17.9 kW (24 hp).
What fuel does the Toro Wheel Horse TX525 use?
The Toro Wheel Horse TX525 uses diesel fuel. Its listed fuel tank capacity is 23 L (6.1 US gal).
What jobs is this Skid Steer Loaders best suited for?
With a 250 kg rated operating capacity, 1,170 mm dump height, and 1,041 mm width without bucket, this Skid Steer Loaders may suit compact material-handling and loading work. Actual job suitability depends on the attachment, material, site conditions, and required capacity.
What is the expected lifespan of the TX525?
The supplied data does not confirm an expected service life for the TX525. For a used machine, inspect maintenance records, engine condition, hydraulic performance, traction drive operation, and structural wear to assess its remaining condition.
What should a buyer check when purchasing a used Skid Steer Loaders?
Check the diesel engine for starting and running condition, inspect hydraulic hoses and couplers for leaks, and test the dual hydrostatic traction drive. Examine the bucket, attachment interface, ROPS, tires or tracks, controls, and service records for damage, wear, or overdue maintenance.
