Mayrath WRX861 Grain Auger
Mayrath WRX861
5+
sold in last yearGeneral overview
The Mayrath WRX861 is a grain auger manufactured in the United States for moving grain in farm handling operations. It is designed for 540 RPM tractor PTO operation and also has a recommended electric rating of 11 kW (15 hp). The model is rated for up to 3,000 BPH.
Its working range is defined by a raised height of 12,217 mm (40 ft 1 in), a lowered reach of 8,077 mm (26 ft 6 in), and a raised reach of 5,664 mm (18 ft 7 in). A 203 mm (8 in) intake diameter and 26 kW (35 hp) recommended tractor PTO horsepower support grain transfer in farm handling setups at extended distances.
Year
2020
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
762 mm
~30 in
2,946 mm
~116 in
4,876 mm
~192 in
998 kg
~2,200.2 lb
Capacity (bushels per hour)
Up to 3,000 BPH
Recommended PTO Horsepower
35 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
PTO drive
Recommended Horsepower - Electric
15 hp
HP Intake Diameter
203 mm
Height - Raised
12,217 mm
Reach - Lowered
8,077 mm
Reach - Raised
5,664 mm
Tube Thickness
14 GA
Flighting - Standard Intake
10 GA Welded with Wear Edge Technologyâ„¢ Lower Pitch for High Capacity
Flighting - Main
7" OD x 10 GA Stretched + Welded
Top Drive Chain
#80 Roller Chain & Hardened Steel Sprockets
Undercarriage Axle
2-½"" x 1 /8"" Wall Sq. Tubing
Tire Size
15" Agricultural Tires
Lift Mechanism
3" OD x 11 GA A-Frame
Mayrath WRX861 Grain Auger Listings
Looking for Mayrath WRX861 Grain Auger?
See similar listingsCompare Mayrath WRX861 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath WRX861?
No confirmed market price is supplied for the Mayrath WRX861. Check current listings and compare the auger’s condition, location, and configuration.
What are the key advantages of the Mayrath WRX861?
Listed features include capacity up to 3,000 BPH, 10 GA welded intake flighting with Wear Edge Technologyâ„¢ and a lower pitch, plus 7" OD x 10 GA stretched and welded main flighting. It also has a #80 roller-chain top drive with hardened steel sprockets.
What type of engine does the WRX861 use?
The supplied specifications do not identify an engine type. They list tractor PTO operation at 540 RPM and an electric horsepower recommendation of 11.2 kW (15 hp).
How much horsepower does the WRX861 have?
The recommended tractor PTO power is 26.1 kW (35 hp). For electric operation, the recommended power is 11.2 kW (15 hp).
What fuel does the Mayrath WRX861 use?
The supplied information does not confirm a fuel type. The WRX861 specifications reference tractor PTO operation and an electric horsepower recommendation rather than an onboard engine.
What jobs is this Grain Auger best suited for?
With capacity up to 3,000 BPH, the Mayrath WRX861 is suited for grain transfer tasks where an auger is needed. Its raised height is 12,217 mm (481 in), with raised reach of 5,664 mm (223 in).
What is the expected lifespan of the WRX861?
No expected service life is supplied for the WRX861. When evaluating one, inspect the flighting, tube, top drive chain, sprockets, lift mechanism, undercarriage, and agricultural tires for wear or damage.
What should a buyer check when purchasing a used Grain Auger?
Inspect the auger tube and flighting for wear, damage, and repairs. Check the #80 roller chain and hardened steel sprockets, lift mechanism, axle tubing, and 15" agricultural tires. Verify PTO compatibility at 540 RPM and confirm that all operating and safety components function properly.
