Mayrath WRX1031 Grain Auger
Mayrath WRX1031
5+
sold in last yearGeneral overview
Mayrath WRX1031 is a grain auger for moving grain in farm handling operations. It is set up for 540 RPM tractor PTO use and lists a recommended PTO horsepower of 22 kW (30 hp), with a capacity of up to 4,800 BPH.
It also lists a recommended horsepower - electric of 7 kW (10 hp) and an intake diameter of 254 mm (10 in). The auger measures 4,725 mm (15 ft 6 in) raised, with reaches of 3,835 mm (12 ft 7 in) lowered and 3,480 mm (11 ft 5 in) raised, and uses 10 GA Welded with Wear Edge Technologyâ„¢ Lower Pitch for High Capacity intake flighting, 9" OD x 7 GA Stretched + Welded main flighting, and #80 Roller Chain & Hardened Steel Sprockets.
Year
2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
762 mm
~30 in
4,876 mm
~192 in
9,450 mm
~372 in
907 kg
~1,999.6 lb
Capacity (bushels per hour)
Up to 4,800 BPH
Recommended PTO Horsepower
30 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
string
Recommended Horsepower - Electric
10 hp
HP Intake Diameter
254 mm
Height - Raised
4,725 mm
Reach - Lowered
3,835 mm
Reach - Raised
3,480 mm
Tube Thickness
12 GA
Flighting - Standard Intake
10 GA Welded with Wear Edge Technologyâ„¢ Lower Pitch for High Capacity
Flighting - Main
9" OD x 7 GA Stretched + Welded
Top Drive Chain
#80 Roller Chain & Hardened Steel Sprockets
Undercarriage Axle
2" x 11 GA Tubing
Tire Size
15" Agricultural Tires
Lift Mechanism
2-½" x 14 GA A-Frame
Mayrath WRX1031 Grain Auger Listings
Looking for Mayrath WRX1031 Grain Auger?
See similar listingsCompare Mayrath WRX1031 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath WRX1031?
No confirmed market price is supplied for the Mayrath WRX1031. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Mayrath WRX1031?
Listed features include capacity up to 4,800 BPH, a 254 mm (10 in) intake, 10 GA welded intake flighting with Wear Edge Technologyâ„¢ and lower pitch, plus 9" OD x 7 GA stretched and welded main flighting.
What type of engine does the WRX1031 use?
The supplied specifications do not identify an engine. The WRX1031 is listed with tractor PTO operation at 540 RPM and an electric horsepower recommendation.
How much horsepower does the WRX1031 have?
Recommended tractor PTO horsepower is 22.4 kW (30 hp). For electric operation, the recommended horsepower is 7.5 kW (10 hp).
What fuel does the Mayrath WRX1031 use?
The supplied data does not confirm a fuel type. It lists tractor PTO operation and an electric horsepower recommendation rather than a self-contained engine.
What jobs is this Grain Auger best suited for?
The supplied specifications support grain-handling applications requiring an auger with capacity up to 4,800 BPH. Suitability for specific crops, bin sizes, or unloading setups is not confirmed in the supplied data.
What is the expected lifespan of the WRX1031?
The supplied data does not provide an expected lifespan. Inspect flighting, the top drive chain and sprockets, tube condition, lift mechanism, undercarriage axle, and tires; maintenance history and operating conditions also matter.
What should a buyer check when purchasing a used Grain Auger?
Check the flighting and tube for wear or damage, inspect the top drive chain and hardened steel sprockets, test the lift mechanism, and examine the undercarriage axle and agricultural tires. Review maintenance history and confirm PTO or electric setup compatibility.
