Mayrath WRX 1071 Grain Auger
Mayrath WRX 1071
5+
sold in last yearGeneral overview
Mayrath WRX 1071 is a grain auger for farm grain handling and transfer. It is specified with a 540 RPM tractor PTO and a recommended 15 kW (20 hp) electric power requirement, placing it in a defined power class for moving grain where auger equipment is used. The model is specified for crop transfer in grain-handling applications.
Its capacity is listed at up to 4,800 bph, with a 254 mm (10 in) intake diameter. The auger uses 12 GA tube thickness, 10 GA Welded with Wear Edge Technologyâ„¢ Lower Pitch for High Capacity standard intake flighting, and 9" OD x 7 GA Stretched + Welded main flighting. A #80 Roller Chain & Hardened Steel Sprockets top drive and 3" OD x 11 GA A-Frame lift mechanism support positioning, while raised height reaches 14,150 mm (46 ft 5 in) and reach is 9,525 mm (31 ft 3 in) lowered or 6,934 mm (22 ft 9 in) raised.
Year
2021
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,997 mm
~118 in
4,600 mm
~181.1 in
21,640 mm
~852 in
1,600 kg
~3,527.4 lb
Capacity (bushels per hour)
Up to 4,800 bph
Recommended PTO Horsepower
60
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
Belt drive
Recommended Horsepower - Electric
20 hp
HP Intake Diameter
254 mm
Height - Raised
14,150 mm
Reach - Lowered
9,525 mm
Reach - Raised
6,934 mm
Tube Thickness
12 GA
Flighting - Standard Intake
10 GA Welded with Wear Edge Technologyâ„¢ Lower Pitch for High Capacity
Flighting - Main
9" OD x 7 GA Stretched + Welded
Top Drive Chain
#80 Roller Chain & Hardened Steel Sprockets
Wheel Track Width
2,997 mm
Undercarriage Axle
2-½"" x 1 /8"" Wall Sq. Tubing
Tire Size
15" Agricultural Tires
Lift Mechanism
3" OD x 11 GA A-Frame
Mayrath WRX 1071 Grain Auger Listings
Looking for Mayrath WRX 1071 Grain Auger?
See similar listingsCompare Mayrath WRX 1071 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Mayrath WRX 1071 Grain Auger
540 RPM
1600 kg
21640 mm × 2997 mm × 4600 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath WRX 1071?
No confirmed market price is supplied for the Mayrath WRX 1071. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Mayrath WRX 1071?
Listed features include capacity of up to 4,800 bph, 10 GA welded intake flighting with Wear Edge Technologyâ„¢ and lower pitch, 9" OD x 7 GA stretched and welded main flighting, and a #80 roller-chain top drive with hardened steel sprockets.
What type of engine does the WRX 1071 use?
The supplied specifications do not identify an engine for the WRX 1071. They list a tractor PTO requirement of 540 RPM and an electric recommendation of 14.9 kW (20 hp).
How much horsepower does the WRX 1071 have?
For electric operation, the recommended horsepower is 14.9 kW (20 hp). The listed tractor PTO speed is 540 RPM.
What fuel does the Mayrath WRX 1071 use?
The supplied information does not confirm a fuel type for the Mayrath WRX 1071. It lists tractor PTO and electric-operation specifications.
What jobs is this Grain Auger best suited for?
The supplied data identifies the WRX 1071 as a Grain Auger with capacity of up to 4,800 bph. It is suited to grain-handling tasks where its listed reach, raised height, and power arrangements fit the operation.
What is the expected lifespan of the WRX 1071?
The supplied information does not provide an expected service life for the WRX 1071. Service life depends on use, maintenance, storage, and the condition of components such as flighting, chain, sprockets, tires, and the lift mechanism.
What should a buyer check when purchasing a used Grain Auger?
Inspect the flighting and wear edge for wear or damage, check the roller chain and sprockets, examine the tube and undercarriage for corrosion or cracks, and verify tire condition. Test the lift mechanism and confirm that the PTO or electric setup matches the intended operation.
