Mayrath New 05-A334 Grain Auger
Mayrath New 05-A334
5+
sold in last yearGeneral overview
Mayrath New 05-A334 is a grain auger for farm equipment attachment use, designed for moving grain during loading and transfer operations. It is configured for 12V electric operation with no hydraulic requirements, and it lists a recommended PTO horsepower of 29 kW (40 hp) at a tractor PTO speed of 1,000 rpm. The model also specifies a recommended electric horsepower of 11 kW (15 hp) and an HP intake diameter of 330 mm (13 in).
The New 05-A334 uses a heavy-duty scissor-lift frame with 12V remote electric landing gear, commercial strength trussing, and a low-profile hopper design. Key size figures include a reach of 15,240 mm (50 ft) lowered and 16,764 mm (55 ft) raised, plus a raised height of 5,486 mm (18 ft) or 6,096 mm (20 ft) with AugerMOVER. Transport length is 18,288 mm (60 ft), and operating weight is 762 kg (1,680 lb).
Year
2023, 2024
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
16,764 mm
~660 in
4,572 mm
~180 in
2,896 mm
~114 in
Tractor PTO speed
1,000
Capacity (bushels per hour)
272,760 L/min
Recommended PTO Horsepower
40 hp
Tractor PTO RPM
550
Additional specifications
Drive type
PTO
Operating Weight
762 kg
Operating width
1,219 mm
Wheel Size
16.5 x 16.1
Upper Bar Length
1,219 mm
Recommended Horsepower - Electric
15 hp
HP Intake Diameter
330 mm
Height - Raised
5,486 mm
Height - Raised (with AugerMOVER)
6,096 mm
Reach - Lowered
15,240 mm
Reach - Raised
16,764 mm
Reach - Intake
1,219 mm
Tube Thickness
3,05 mm
Flighting - Standard Intake
13" OD x 8" ID formed flighting
Flighting - HP Intake
13 mm
Flighting - Main
13" OD x 8" ID continuous formed
1/4" Core Diameter
203 mm
Top Drive Chain
#80 chain (1-1/4" pitch)
Transport Length
18,288 mm
Transport Height
4,572 mm
Wheel Track Width
2,896 mm
Frame Arms
Commercial strength trussing, low-profile hopper design
Hydraulic Requirements
None (12V electric)
Tire Size
16.5L x 16.1 SL
Tire Ply Rating
14
Height w/ Extension
1,219 mm
Number of Wheels
4
Lift Mechanism
Heavy-duty scissor-lift frame with 12V remote electric landing gear
Mayrath New 05-A334 Grain Auger Listings
Looking for Mayrath New 05-A334 Grain Auger?
See similar listingsCompare Mayrath New 05-A334 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Mayrath New 05-A334 Grain Auger
272760 L/min
16764 mm × 2896 mm × 4572 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath New 05-A334?
No confirmed market price is supplied for the Mayrath New 05-A334. Check current listings and compare machine condition, location, and configuration.
What are the key advantages of the Mayrath New 05-A334?
Listed features include a heavy-duty scissor-lift frame, 12V remote electric landing gear, commercial-strength trussing, a low-profile hopper, and four wheels. It requires no hydraulic supply, using 12V electric operation.
What type of engine does the New 05-A334 use?
The supplied specifications do not identify an engine for the New 05-A334. They list recommended PTO and electric horsepower requirements instead.
How much horsepower does the New 05-A334 have?
The New 05-A334 has a recommended PTO requirement of 29.8 kW (40 hp). Recommended electric horsepower is 11.2 kW (15 hp).
What fuel does the Mayrath New 05-A334 use?
The supplied data does not confirm a fuel type for the Mayrath New 05-A334. It lists PTO operation and 12V electric components but does not specify fuel.
What jobs is this Grain Auger best suited for?
As a Grain Auger, the Mayrath New 05-A334 is suited for grain-transfer work. Its listed reach, raised height, low-profile hopper, and scissor-lift frame may be relevant when evaluating fit for a specific handling setup.
What is the expected lifespan of the New 05-A334?
The supplied data does not provide an expected lifespan. Service life depends on use, maintenance, storage, and condition. Inspect the tube, flighting, drive chain, lift mechanism, tires, and electrical components before purchase.
What should a buyer check when purchasing a used Grain Auger?
Check the tube and flighting for wear or damage, inspect the drive chain and lift mechanism, and test the 12V electrical system and landing gear. Also inspect the hopper, frame trussing, tires, wheels, and any signs of corrosion or repairs.
