Mayrath HX_871 Grain Auger
Mayrath HX_871
Average price
$14,990
5+
sold in last year
General overview
Mayrath HX_871 is a grain auger manufactured in the United States for 2022 and 2023. It is designed for farm grain handling, moving harvested grain in agricultural transfer and storage operations. The model is set up for 540 RPM tractor PTO operation and has a recommended PTO horsepower of 29 kW (40 hp), with a capacity of 3300 – 3900 Bu/Hr.
Its 200 mm (8 in) intake diameter supports grain intake at the auger inlet, while the minimum 2500 psi (17200 kPa) working pressure defines its hydraulic requirement. For transport between work areas, the unit has a length of 21,640 mm (71 ft) and a height of 4,420 mm (14 ft 6 in), which are important considerations when positioning and moving the auger on the farm.
Year
2022, 2023
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,997 mm
~118 in
4,430 mm
~174.4 in
21,646 mm
~852.2 in
1,057 kg
~2,330.3 lb
Capacity (bushels per hour)
3,300 – 3,900 Bu/Hr
Recommended PTO Horsepower
40 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
PTO drive
HP Intake Diameter
200 mm
Transport Length
21,640 mm
Transport Height
4,420 mm
Weight - Hitch
2,000 lb
Hydraulic Requirements
Minimum 2,500 psi (17,200 kPa) working pressure
Tire Size
15" Automotive Tires
Mayrath HX_871 Grain Auger Listings
Compare Mayrath HX_871 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath HX_871?
No confirmed market price is supplied for the Mayrath HX_871. Check current listings and compare the machine’s condition, location, and configuration.
What are the key advantages of the Mayrath HX_871?
Listed HX_871 specifications include 3300 – 3900 Bu/Hr capacity, a 200 mm (7.9 in) HP intake diameter, 540 RPM tractor PTO operation, and a recommended PTO rating of 29.8 kW (40 hp).
What type of engine does the HX_871 use?
The supplied specifications do not identify an engine for the HX_871. They specify operation from a tractor PTO at 540 RPM.
How much horsepower does the HX_871 have?
The HX_871 has a recommended PTO requirement of 29.8 kW (40 hp).
What fuel does the Mayrath HX_871 use?
The supplied data does not confirm a fuel type for the Mayrath HX_871. Its listed power source is a tractor PTO operating at 540 RPM.
What jobs is this Grain Auger best suited for?
As a Grain Auger, the Mayrath HX_871 is suited to grain-handling work where tractor PTO-powered transfer is needed. Its listed capacity is 3300 – 3900 Bu/Hr.
What is the expected lifespan of the HX_871?
The supplied information does not provide an expected service life for the HX_871. Lifespan depends on operating conditions, maintenance, storage, and the condition of components.
What should a buyer check when purchasing a used Grain Auger?
Inspect the auger, intake, hitch, tires, hydraulic components, and PTO-related parts for wear, damage, leaks, and safe operation. Confirm that hydraulic equipment meets the listed minimum 2500 psi (17200 kPa) working pressure requirement.
