Mayrath HX_861 Grain Auger
Mayrath HX_861
5+
sold in last yearGeneral overview
Mayrath HX_861 is a grain auger used for moving harvested grain in farm handling and transfer operations. Produced in 2023 in the United States, it is designed for tractor-powered use with a 540 RPM PTO and a recommended PTO horsepower of 33 kW (45 hp).
The model is rated for 3300 – 3900 Bu/Hr and uses a 200 mm (8 in) intake diameter, which helps define its grain feed opening. Transport dimensions of 18,592 mm (61 ft) in length and 4,120 mm (13 ft 6 in) in height show its large working scale, and minimum 2500 psi (17200 kPa) hydraulic working pressure supports operation.
Year
2023
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
2,844 mm
~112 in
4,120 mm
~162.2 in
18,592 mm
~732 in
957 kg
~2,109.8 lb
Capacity (bushels per hour)
3,300 – 3,900 Bu/Hr
Recommended PTO Horsepower
45 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
PTO drive
HP Intake Diameter
200 mm
Transport Length
18,592 mm
Transport Height
4,120 mm
Weight - Hitch
2,000 lb
Hydraulic Requirements
Minimum 2,500 psi (17,200 kPa) working pressure
Tire Size
15" Automotive Tires
Mayrath HX_861 Grain Auger Listings
Looking for Mayrath HX_861 Grain Auger?
See similar listingsCompare Mayrath HX_861 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath HX_861?
No confirmed market price is supplied for the Mayrath HX_861. Check current listings and compare the unit’s condition, location, and configuration.
What are the key advantages of the Mayrath HX_861?
The supplied specifications list a capacity of 3300 – 3900 Bu/Hr, a 540 RPM tractor PTO requirement, and recommended PTO power of 33.6 kW (45 hp). It also has a 200 mm (7.9 in) HP intake diameter and hydraulic requirements of Minimum 2500 psi (17200 kPa) working pressure.
What type of engine does the HX_861 use?
The supplied data does not identify an engine for the HX_861. It lists operation from a tractor PTO at 540 RPM rather than an engine specification.
How much horsepower does the HX_861 have?
The HX_861 has a recommended PTO horsepower requirement of 33.6 kW (45 hp). The supplied data does not state a separate engine horsepower rating.
What fuel does the Mayrath HX_861 use?
The supplied data does not specify a fuel type for the Mayrath HX_861. It identifies the unit as tractor PTO-driven at 540 RPM.
What jobs is this Grain Auger best suited for?
As a Grain Auger, the HX_861 is suited to grain-handling tasks where a tractor can provide 540 RPM PTO power. Its stated capacity is 3300 – 3900 Bu/Hr. Confirm that the available tractor meets the recommended 33.6 kW (45 hp) PTO requirement and hydraulic pressure requirement.
What is the expected lifespan of the HX_861?
The supplied data does not provide an expected service-life estimate for the HX_861. Lifespan depends on operating conditions, storage, maintenance, and the condition of components such as the auger, drive system, tires, and hydraulic equipment.
What should a buyer check when purchasing a used Grain Auger?
Inspect the auger tube and flighting for wear or damage, and test the PTO drive, hitch, hydraulics, tires, and safety guards. Verify that the hydraulic system can meet Minimum 2500 psi (17200 kPa) working pressure and that the tractor can provide 540 RPM PTO power.
