Mayrath HX_1083 Grain Auger
Mayrath HX_1083
5+
sold in last yearGeneral overview
Mayrath HX_1083 is a grain auger attachment from Mayrath, produced in 2023 in the United States. It is used for grain transfer in harvest and storage handling setups. The model is specified for 540 RPM PTO operation and a recommended PTO horsepower of 55 kW (75 hp), with a capacity of 23,000 bu/h.
For compatibility and structure, the HX_1083 includes a 12 GA tube, 9" OD x 7 GA Stretched + Welded (Extended Wear at Critical Transfer Points) main flighting, and a #60 top drive chain. It also lists a 4" x 8" Scissor Lift, 1600 PSI hydraulic requirements, a lowered reach of 12,725 mm (41 ft 9 in), and a wheel track width of 3,352 mm (11 ft).
Year
2023
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,353 mm
~132 in
4,064 mm
~160 in
25,300 mm
~996.1 in
3,175 kg
~6,999.7 lb
Capacity (bushels per hour)
23,000 bu/h
Recommended PTO Horsepower
75 hp
Tractor PTO RPM
540 RPM
Additional specifications
Drive type
PTO drive
Height - Raised
16.85 mm
Reach - Lowered
12,725 mm
Reach - Raised
9.779 mm
Tube Thickness
12 GA
Flighting - Main
9" OD x 7 GA Stretched + Welded (Extended Wear at Critical Transfer Points)
Top Drive Chain
#60
Transport Length
25.3 mm
Transport Height
4.064 mm
Wheel Track Width
3,352 mm
Undercarriage Axle
3" x 6" Tubing
Hydraulic Requirements
1,600 PSI
Tire Size
16" TRF
Lift Mechanism
4" x 8" Scissor Lift
Mayrath HX_1083 Grain Auger Listings
Looking for Mayrath HX_1083 Grain Auger?
See similar listingsCompare Mayrath HX_1083 Grain Auger to other grain auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Mayrath HX_1083?
No confirmed market price is supplied for the Mayrath HX_1083. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Mayrath HX_1083?
Listed features include a capacity of 23,000 bu/h, 540 RPM tractor PTO operation, a 4" x 8" scissor lift, and extended-wear flighting at critical transfer points. It also has a #60 top drive chain and a 3" x 6" tubing undercarriage axle.
What type of engine does the HX_1083 use?
No engine type is supplied for the HX_1083. The available specifications identify it as tractor PTO-driven at 540 RPM.
How much horsepower does the HX_1083 have?
The recommended tractor PTO horsepower is 55.9 kW (75 hp).
What fuel does the Mayrath HX_1083 use?
No fuel type is supplied for the Mayrath HX_1083. Its listed power source is a tractor PTO operating at 540 RPM.
What jobs is this Grain Auger best suited for?
The supplied information identifies the HX_1083 as a Grain Auger with a listed capacity of 23,000 bu/h. Specific recommended jobs or grain-handling applications are not confirmed in the supplied data.
What is the expected lifespan of the HX_1083?
The supplied data does not provide an expected lifespan for the HX_1083. Inspect the flighting, top drive chain, lift mechanism, hydraulic components, tires, and undercarriage for wear and maintenance condition.
What should a buyer check when purchasing a used Grain Auger?
Check the flighting and tube for wear or damage, inspect the #60 top drive chain and lift mechanism, and look for hydraulic leaks or faults. Examine tires, the undercarriage axle, PTO connection, guards, and overall operating condition.
