Manitou MT420 Telehandler
Manitou MT420
Average price
$94,930
5+
sold in last year
General overview
Manitou MT420 is a construction equipment model from Manitou used for construction-site work. It has an operating weight of 4,250 kg (9,370 lb) and a net power rating of 41 kW (56 hp) from a Kubota V2403-M-D engine. The listed weight and power are the main size and output markers.
A 2-speed hydrostatic transmission and Tier 4 Final emission standard level define its operating setup. The 4-cylinder, 2 L engine is paired with a hydraulic system of 76 L (20 US gal), a pump flow of 70 L/min (18.5 gpm), and a system relief pressure of 235 bar (3,410 psi). Operator control is via a Manitou JSM joystick with integrated machine and hydraulic controls, and standard road and work lights with warning beacon are listed.
Year
2019, 2020, 2021, 2022, 2023, 2024, 2025, 2026
Country of manufacturing
France
General specifications
Dimensions
Length
Height
Width
3,675 mm
~144.7 in
1,947 mm
~76.7 in
1,490 mm
~58.7 in
Operating Weight
4,250 kg
Power
56 hp
Boom Lift Capacity
2,000 kg
Maximum Lift Height
4.3 m
Additional specifications
Emission standard level
Tier 4 Final
Displacement
2 cu(m)
Transmission type
2-speed hydrostatic
Fuel tank
80 L
Cooling system
8 L
Control
Manitou JSM joystick with integrated machine and hydraulic controls
Main Pumps
65 L/sec
System Relief Pressure
23,500 kPa
Engine Model
Kubota V2,403-M-D
Engine Oil
10 L
Power - Net
56 hp
Pump Flow
70 L/min
Hydraulic System
76 L
Lights
Standard road and work lights with warning beacon; exact count/type not published
Rated Operating Capacity
2,000 kg
Cylinders
4
Manitou MT420 Telehandler Listings
Compare Manitou MT420 Telehandler to other telehandler
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Manitou MT420?
No confirmed market price is supplied for the Manitou MT420. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Manitou MT420?
The supplied specifications list a Kubota V2403-M-D engine with 41.8 kW (56 hp), a 2-speed hydrostatic transmission, Manitou JSM joystick controls, and standard road and work lights with a warning beacon. Exact light count and type are not published.
What type of engine does the MT420 use?
The MT420 uses a Kubota V2403-M-D engine. It has 4 cylinders, is rated at 41.8 kW (56 hp), and meets Tier 4 Final emissions requirements.
How much horsepower does the MT420 have?
The Manitou MT420 is rated at 56 hp (41.8 kW) net power.
What fuel does the Manitou MT420 use?
The supplied specifications do not confirm the fuel type for the Manitou MT420. They list an 80 L (21.1 US gal) fuel tank and a Kubota V2403-M-D engine.
What jobs is this Other construction equipment best suited for?
The supplied data does not specify particular job applications for the Manitou MT420. Its listed equipment includes 2-speed hydrostatic transmission, joystick controls, and road and work lights, but suitability should be confirmed against the required attachment, load, and site conditions.
What is the expected lifespan of the MT420?
The supplied data does not provide an expected service life for the Manitou MT420. Assess maintenance records, operating condition, fluid leaks, hydraulic performance, engine operation, transmission response, controls, and overall wear when evaluating a unit.
What should a buyer check when purchasing a used Other construction equipment?
Check maintenance records, engine starting and operation, fluid condition and leaks, hydraulic performance, transmission response, controls, lights, warning beacon, tires or running gear, structural damage, and signs of excessive wear. Confirm that the machine’s configuration and attachments suit the intended work.
