Kinze 850 Single Auger
Kinze 850
5+
sold in last yearGeneral overview
Year
2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012
Country of manufacturing
United States
General specifications
Dimensions
Length
Height
Width
6,629 mm
~261 in
3,454 mm
~136 in
3,658 mm
~144 in
Unloading rate
212 L/min
Grain Cart Capacity
29,900 L
Required Engine Power
186.42 kW
Grain Cart Loaded Tongue Weight
2,268 kg
Grain Cart Empty Tongue Weight
1,134 kg
Grain Cart Auger Diameter
0.51 m
Flighting Thickness
20 in flighting in 21 in tube
Hub Size/Spindle Diameter
20 bolt 13.189 bolt center
Hydraulic Remotes Required
3 SCVs
Front/Rear Slopes
Steep front and rear slopes, 30°
Hopper Length
5.86 m
Hopper Width
3.75 m
Auger Side Reach Max
2.21 m
Auger Side Reach Min
2.21 m
Grain Cart Overall Transport Length
8.63 m
Additional specifications
Peak unloading rate
17,619 L/min
Ð ower requirement
180 hp
Capacity Heaped
29,953 cu(m)
Tractor hydraulics requirements
1–2 rear hydraulic remotes (SCVs) depending on configuration; tractor hydraulic system capable of approximately 2,800–3,000 psi. Manual does not specify an explicit hydraulic flow (L/min) requirement.
Total weight - empty
11,294 kg
Hitch weight - empty
1,791 kg
Hitch weight - loaded
2,848 kg
Vertical auger
432 mm
Horizontal auger
432 mm
Gearbox
Right-angle PTO drive gearbox (Kinze gearbox assembly); no gear ratio or torque rating specified in manual.
Drive belts
None for main auger drive (PTO shaft and gearboxes used)
Drive sheaves
None for main auger drive
PTO speed
1,000
