Kinze 3700 Row Crop Planters — Drawn
Kinze 3700
Average price
$21,900
5+
sold in last year
General overview
Kinze 3700 is an air drill and seeder used for field planting in farm operations. Manufactured in the United States and produced from 2003 to 2011, it combines a 1,177 L (33.4 bu) seed tank with Tru‑Vee double-disc openers and finger-pickup metering for row-crop seeding.
The machine is arranged as 24 row units in a single rank with 762 mm (30 in) row spacing and 762 mm (30 in) between ranks. Its Tru‑Vee double-disc seed openers support a row-oriented planting setup for sowing crops in prepared fields, and the tank and opener layout help define the model’s working scale within air seeding equipment. The 24-row arrangement supports broad coverage across planting passes while keeping the layout consistent from row to row. The 1,177 L (33.4 bu) tank capacity also supports longer intervals between fills.
Year
2003, 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
4,170 mm
~164.2 in
3,280 mm
~129.1 in
3,960 mm
~155.9 in
9,229 kg
~20,346.5 lb
Seed-tank capacity
33.4 bu
Seed Hopper Capacity
67 L per hopper (mechanical); 62 L per hopper (vacuum)
Planter – Number of rows
24
Base Seed Meter
Mechanical finger pickup
Planter Tire Base
Transport tires: 7.50 x 20, 8-ply rib implement tires
Row Units Type
Kinze pull-type row units
Row Units Opener
Double-disc opener
Markers Type
Three-fold hydraulic markers with 16-inch concave discs
Additional specifications
Row Spacing
762 mm
Openers system
Tru‑Vee double-disc openers with finger-pickup metering
Standard features
Flex-fold frame, central-fill ASD system, finger-pickup meters, electric row shutoffs, ground-drive transmission, spring downforce, unit-mounted coulters, row cleaners, Ag-Leader monitor, markers, scrapers
Number of openers
24 row units
Number of ranks
1
Space between ranks
762 mm
Seed openers
Tru‑Vee double-disc units
Kinze 3700 Row Crop Planters — Drawn Listings
$21,900
Flex-fold frame, central-fill ASD system, finger-pickup meters, electric row shutoffs, ground-drive transmission, spring downforce, unit-mounted coulters, row cleaners, Ag-Leader monitor, markers, scrapers
33.4 bu
Tru‑Vee double-disc openers with finger-pickup metering
Assumption, United States
Compare Kinze 3700 Row Crop Planters — Drawn to other row crop planters — drawn
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Kinze 3700 Row Crop Planters — Drawn
33.4 bu
9229 kg
3960 mm × 4170 mm × 3280 mm
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Kinze 3700?
No confirmed market price is supplied. Check current listings and compare condition, location, and configuration.
What are the key advantages of the Kinze 3700?
Supplied features include 24 row units on 762 mm (30 in) spacing, Tru‑Vee double-disc openers, finger-pickup metering, and a 33.4 bu seed-tank capacity.
What type of engine does the 3700 use?
The supplied specifications do not confirm an engine type for the Kinze 3700.
How much horsepower does the 3700 have?
The supplied specifications do not confirm a horsepower rating for the Kinze 3700.
What fuel does the Kinze 3700 use?
The supplied specifications do not confirm the fuel type for the Kinze 3700.
What jobs is this Air Drills and Seeders best suited for?
Based on the supplied configuration, it is suited to row-crop seeding with 24 row units at 762 mm (30 in) spacing. It uses Tru‑Vee double-disc openers and finger-pickup metering.
What is the expected lifespan of the 3700?
The supplied data does not confirm an expected service life. Inspect opener condition, metering components, row units, seed-tank condition, and maintenance history when assessing a machine.
What should a buyer check when purchasing a used Air Drills and Seeders?
Check the condition and operation of the Tru‑Vee double-disc openers, finger-pickup metering, all 24 row units, seed tank, and frame. Review maintenance history and verify that row spacing is 762 mm (30 in).
