Kinze 1500 Single Auger
Kinze 1500
5+
sold in last yearGeneral overview
The Kinze 1500 is a grain cart from Kinze, used to receive and transfer grain during harvest in field operations. It has a Capacity Heaped: 52.9 m³ (69.2 cu yd) and a Total weight - empty: 2,291 kg (5,050 lb), which define its basic size and grain-handling role.
For unloading and material flow, the model uses a Vertical auger: 559 mm (22 in) and a Horizontal auger: 508 mm (20 in). It is specified with a PSI capacity: 160 bar (2,320 psi) and PTO: 1 000 rpm, with a Hitch weight - loaded: 3,266 kg (7,200 lb).
Year
2014, 2015, 2016, 2017, 2018, 2019, 2020, 2021, 2022
Country of manufacturing
United States
General specifications
Dimensions
Width
Height
Length
Weight
3,962 mm
~156 in
3,454 mm
~136 in
11,836 mm
~466 in
13,999 kg
~30,862.5 lb
Unloading rate
1,233.48 L/min
Capacity Heaped
52.9 cu(m)
Grain Cart Capacity
52,869 L
Required Engine Power
223.71 kW
Grain Cart Loaded Tongue Weight
3,265.87 kg
Grain Cart Empty Tongue Weight
2,290.64 kg
Grain Cart Auger Diameter
0.56 m
Flighting Thickness
1/4 in edge; 7/16 in root
Hub Size/Spindle Diameter
6-bolt rear cast iron hubs; 2 in front ball bearing
Hydraulic Remotes Required
5 SCVs manual or 2 SCVs remote
Front/Rear Slopes
18° front and 12° rear
Hopper Length
8.84 m
Hopper Width
3.66 m
Auger Side Reach Max
4.57 m
Auger Side Reach Min
3.05 m
Grain Cart Overall Transport Length
11.84 m
Additional specifications
Peak unloading rate
6,973 gpm
PTO
1 000 rpm
Track size
889 mm × 2 743 mm
Total weight - empty
2,291 kg
Hitch weight - loaded
3,266 kg
PSI capacity
16,000 kPa
Vertical auger
559 mm
Horizontal auger
508 mm
Gearbox
2 : 1
Drive belts
2 multi-strand V-belts
Drive sheaves
235 mm / 475 mm
Kinze 1500 Single Auger Listings
Looking for Kinze 1500 Single Auger?
See similar listingsCompare Kinze 1500 Single Auger to other single auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Kinze 1500?
No confirmed market price is supplied. Check current listings while comparing condition, location, and configuration.
What are the key advantages of the Kinze 1500?
Listed strengths include 52.9 m³ (69.19 cu yd) heaped capacity and a peak unloading rate of 26,395.7 L/min (6,973 gpm). Its unloading system includes a 559 mm (22 in) vertical auger, 508 mm (20 in) horizontal auger, and 1 000 rpm PTO.
What type of engine does the 1500 use?
The supplied specifications do not confirm an engine type for the Kinze 1500.
How much horsepower does the 1500 have?
The supplied specifications do not confirm a horsepower rating for the Kinze 1500.
What fuel does the Kinze 1500 use?
The supplied specifications do not confirm a fuel type for the Kinze 1500.
What jobs is this grain cart best suited for?
The Kinze 1500 is suited to grain-cart work involving grain handling and unloading. Its listed 52.9 m³ (69.19 cu yd) heaped capacity and peak unloading rate of 26,395.7 L/min (6,973 gpm) are relevant when moving grain during harvest operations.
What is the expected lifespan of the 1500?
The supplied data does not provide an expected service life. For a used unit, inspect the augers, belts, gearbox, tracks, hitch, and unloading system, and review maintenance history.
What should a buyer check when purchasing a used grain cart?
Check the 559 mm (22 in) vertical auger and 508 mm (20 in) horizontal auger for wear, along with the gearbox, two multi-strand V-belts, drive sheaves, PTO, hitch, tracks, and unloading operation. Also inspect for structural damage and maintenance records.
