Kinze 1121 Dual Auger
Kinze 1121
5+
sold in last yearGeneral overview
Kinze 1121 is a Kinze grain cart built for handling harvested grain during field operations. It is rated for a power requirement of 184 kW (250 hp) and has a peak unloading rate of 19,381 L/min (5,119.9 gpm), showing a model focused on rapid grain transfer.
The cart uses a heavy-duty right-angle PTO gearbox with a 1,000 rpm PTO speed, and the main PTO-to-auger drive does not use belts. Grain moves through 508 mm (20 in) vertical and horizontal augers, which supports high-capacity unloading in harvest logistics. These specifications place the Kinze 1121 in a higher-capacity grain cart class for field-side grain handling.
Year
2022, 2023, 2024, 2025
Country of manufacturing
United States
General specifications
Unloading rate
1,086.67 L/min
Grain Cart Capacity
41,639.48 L
Required Engine Power
186.4 kW
Grain Cart Loaded Tongue Weight
2,840 kg
Grain Cart Empty Tongue Weight
1,733.6 kg
Grain Cart Auger Diameter
0.51 m
Flighting Thickness
20
Hub Size/Spindle Diameter
100 mm spindle diameter
Hydraulic Remotes Required
3 SCVs; 2,320 system psi
Front/Rear Slopes
30° front and 30° rear
Hopper Length
5.89 m
Hopper Width
3.68 m
Auger Side Reach Max
4.57 m
Auger Side Reach Min
2.44 m
Grain Cart Overall Transport Length
9.4 m
Additional specifications
Peak unloading rate
19,381 L/min
Power requirement
250 hp
Capacity Heaped
38,763 cu(m)
Track size
914 mm
Tractor hydraulics requirements
Not published (SCV count, flow, and pressure not specified).
Vertical auger
508 mm
Horizontal auger
508 mm
Gearbox
Heavy-duty right-angle PTO gearbox (ratio/brand not published).
Drive belts
None on main PTO to auger drive; gearbox and chains used instead.
Drive sheaves
Not applicable / not published.
PTO speed
1,000
Kinze 1121 Dual Auger Listings
Looking for Kinze 1121 Dual Auger?
See similar listingsCompare Kinze 1121 Dual Auger to other dual auger
Not sure which equipment to choose? Use our comparison tool to easily compare equipment side by side based on key features.
Add model
Add model
No reviews yet
Be the first to review this model.
Leave a review. Get a promo code
Leave a review and receive a promo code for your next purchase.
No questions yet
Be the first to ask a question about this model and help other buyers learn more.
Heavy equipment insights from JumboBee
Got Questions?
Our FAQ section covers everything from shipping and listing to buying with confidence.
Can't find what you're looking for?
Sign up and talk to an expert.
Most popular
What is the average price of a Kinze 1121?
No confirmed market price is supplied for the Kinze 1121. Check current listings and compare the cart’s condition, location, and configuration.
What are the key advantages of the Kinze 1121?
Published features include a 38,763 m³ (50,700.07 cu yd) heaped capacity, a peak unloading rate of 19,381 L/min (5,119.9 gpm), 508 mm (20 in) vertical and horizontal augers, and 914 mm (36 in) tracks. Its main PTO-to-auger drive uses a gearbox and chains rather than drive belts.
What type of engine does the 1121 use?
The supplied specifications do not identify an engine for the Kinze 1121. It is listed with a power requirement of 186.4 kW (250 hp) and a 1,000 rpm PTO speed.
How much horsepower does the 1121 have?
The Kinze 1121 has a published power requirement of 186.4 kW (250 hp). This is a tractor power requirement, not an engine output listed for the grain cart.
What fuel does the Kinze 1121 use?
The supplied specifications do not state a fuel type for the Kinze 1121. The cart is specified to use a 1,000 rpm PTO and requires 186.4 kW (250 hp) from the tractor.
What jobs is this Grain carts best suited for?
As a grain cart, the Kinze 1121 is suited to moving and unloading grain during harvest. Its published 38,763 m³ (50,700.07 cu yd) heaped capacity and peak unloading rate of 19,381 L/min (5,119.9 gpm) are relevant for high-volume grain transfer operations.
What is the expected lifespan of the 1121?
The supplied data does not provide an expected service life for the Kinze 1121. Service life depends on use, maintenance, storage, and the condition of the augers, gearbox, chains, tracks, and structural components.
What should a buyer check when purchasing a used Grain carts?
Inspect the cart structure, augers, gearbox, chains, PTO components, unloading operation, and 914 mm (36 in) tracks for wear or damage. Verify that the unloading system operates properly and review maintenance records. The tractor hydraulic SCV count, flow, and pressure requirements are not published, so confirm compatibility with the seller.
